Home > Products > Compacted Wire Rope > Increased wear resistance Compacted Strand Wire Rope 8 x K26WS
Increased wear resistance Compacted Strand Wire Rope 8 x K26WS
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Parallel Laid Galvanized Compacted Wire Rope 8 x K31WS + PWRC
-
High Tensile Parallel Laid Compacted Wire Rope 8 x K36WS + PWRC
-
Parallel Laid Linear Contact Steel Wire Rope 6 x 26 WS Construction
-
Crane Derricking Parallel Laid lifting wire rope 6 x 29 Filler Type
-
Linear Contact Parallel Laid Rotating Resistant galvanized wire rope 6 x 31 WS
-
High Flexibility Linear Contact Wire Rope 6 x 65 FNS with 60mm to 120mm
Product Details
| Brand Name | INCHTIGHT | Place of Origin | China | |
Product Description
Certification:Lloyd’s/CCS/ABS/BV/DNV
Increased wear resistance ?Compacted Strand Wire Rope 8 x K26WS + PWRC
About Flattened Wire Rope With Compacted Strands
Compacted wire rope?is composed of several wire strands which have gone through crimping wheels to compress and shape the individual wires to form compacted structures or reduce diameters before laying strands around the core. Taking advantage of the compacting process, the surface of outer wires is flattened and the contact area between strands is increased.
Feature:
Application:
Whip hoist rope. Pillar crane rope. Deck crane rope. Offshore crane rope. Other various hoist ropes. Mining ropes. Machinery. Marine fishing applications.Specifications
|
Nominal Diameter (D/mm) |
Approx Weight (kg/100m) |
Nominal Tensile Strength of Rope (Mpa) |
|||
|
1570 |
1670 |
1770 |
1870 |
||
|
Minimum Breaking Load of Rope (KN) |
|||||
|
14 |
100 |
135 |
144 |
153 |
161 |
|
16 |
131 |
177 |
188 |
199 |
211 |
|
18 |
165 |
224 |
238 |
252 |
267 |
|
20 |
204 |
276 |
294 |
312 |
329 |
|
22 |
247 |
334 |
356 |
377 |
398 |
|
24 |
294 |
398 |
423 |
449 |
474 |
|
26 |
345 |
467 |
497 |
526 |
556 |
|
28 |
400 |
542 |
576 |
611 |
645 |
|
30 |
459 |
622 |
661 |
701 |
741 |
|
32 |
522 |
707 |
752 |
797 |
843 |
|
34 |
590 |
799 |
849 |
900 |
951 |
|
36 |
661 |
895 |
952 |
1010 |
1070 |
|
38 |
736 |
998 |
1060 |
1120 |
1190 |
|
40 |
816 |
1110 |
1180 |
1250 |
1320 |
|
42 |
900 |
1220 |
1300 |
1370 |
1450 |
|
44 |
987 |
1340 |
1420 |
1510 |
1590 |
|
46 |
1080 |
1460 |
1550 |
1650 |
