A192 / A210 Seamless Cold Drawn Heat Exchanger U Tube for Boiler
- T/T L/C D/P D/A
- 7 days
You May Like
-
Stainless Steel Heat Exchanger U Tube ASTM A213 TP304 / 304L TP316 / 316L
-
A179 / A192 / SA210 SMLS Carbon Steel Tube , OD25.4mm I Type Threaded Steel Fin Tube
-
TP316 / 316L SMLS Stainless Steel Tube , OD19mm Corrugation Steel Fin Tube
-
Solid / Plain CuNi 90 /10 Shape Type Cooper Fin Tube OD25.4X1.5WT L
-
C12200 / TP2 Copper Finned Tube , Tension Wrapped L Type Condenser Tube
-
LL Overlapped Type Cooling Aluminumfin Tube of A192 SMLS Carbon Steel
Product Details
| Brand Name | Reliance | Place of Origin | China | |
| Model Number | U Tube |
Product Description
Certification:ISO
?A192 / A210 Seamless U Bend ?Boiler Tubes for Heat Exchangers
ASTM A192/A192M?: Seamless Carbon Steel Boiler Tubes for High-Pressure Service
ASTM A210/A210M :?Seamless Medium-Carbon Steel Boiler and Superheater Tubes
More?Standard and Grade:
ASTM?A210/ASME?SA210?A1
ASTM?A213/ASME?T11? T22?
A106B/A53B/A179/A192/A200/A333/A335/500
ASME?SA106B/A53B/A192/A200/A333/A335/500
BS3059??BS6323-4??BS3602-1
EN10297-1????EN10305-1???EN10216-1???EN10216-2????EN10210-1
DIN1629???DIN1630??DIN?17175 DIN2391???DIN17204??????DIN2448??
JIS?G3452(SGP)???JIS?G3461JIS?G3462??JIS?G3454JIS?G3455??JIS?G3444?
Tube Type:
Seamless (Cold Drawn)?
Both Ends:
Plain ends or bevel ends?
Straight?Tubes?Maximum?Length:
(Before?Bending):?35000?mm.
Unit??Leg Length
Min?1?Meter,?Max.?16500?mm?(For?Max?R=1500mm)
Heat?Treatment
Stress?Relieved?After?U-Bending?(Bending?Area?Plus?300MM?For?Each?Leg).
Hydrostatic?Test?After?U?Bending
Maximum?Test?Pressure?600?Bar, Holding time:?10?Sec.?
Medium:?Dematerialized?Water.?
Compressed?Air?Cleaning?After?Hydro-Test.
Packaging?
In?Strong?Transport-Worthy?Pre-fumigated?wooden boxes?of?corresponding?dimensions?for?
each?tube?Length,?Radius,?Diameter,?According?To?PO requirements as?well?as wrapped?In polyethylene?
films?With soft plastic caps on both end?of?Tube.
General?Quality Tests
| Corrosion Test | Conducted only when specially requested by the client |
| Chemical Analysis | Test done as per required quality standards |
| Destructive / Mechanical Testing | Tensile | Hardness | Flattening | Flare | Flange |
| Reverse-bend and Re. flat tests | Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end |
| Eddy Current Testing | Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System |
| Hydrostatic Testing | 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s . |
| Air Under Pressure Test | To check any evidence of air leakage |
| Visual Inspection | After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections |
Supplementary Testing :?Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:
| Eddy Current Testing O.P Testing Radiography Testing | Corrosion Testing Micro Testing Macro Testing | IGC Testing Ultrasonic testing Liquid Penetrate testing ? |
