Mounted CXF-3000 Magnetic Levitation Generator for BTS Romote Area
- T/T L/C D/P D/A
- 7 days
You May Like
-
Maglev Vawt Wind Turbine for LED Street Light System without traditional wire underground
-
High Stability Domestic Maglev Wind Turbine Generator for Traffic signal
-
Countryside Road Maglev Wind Turbine Vertical Axis Wind Generators
-
200W VAWT Maglev Wind Turbine with Solar Panel for 45W LED Street Light
-
Commercial Maglev Vertical Axis Wind Turbine for LED Advertising Board
-
24V / 48V Small Home Off Grid Wind Turbine 600W , Magnetic Levitation Technology
Product Details
| Brand Name | TYPMAR | Place of Origin | China | |
| Model Number | CXF-3000 |
Product Description
Certification:CE ISO9001 IEC
Mounted CXF-3000 Magnetic Levitation Generator for BTS Romote Area
1. Brief to 3kw wind turbine
CXF-3000 Vertical Axis Maglev Wind Turbine is a breakthrough in wind power technology. It’s Typmar who made magnetic levitation technology used in wind turbine for the first time. This creates a milestone and fulfills important breakthrough in the history of small and medium wind turbine development. The maglev technology improves the efficiency of wind power 35% compared to traditional horizontal axis wind turbine. The innovative wind generators have been widely used for Telecoms Base Receiver Station (BTS) as well as residential and commercial applications.
Quick Detail:
1, No Vibration-Means you can mount anywhere including on your house roof
2, No Noisy-Means quiet enjoyment of living
3, No Frication-Means the equipment lasts longer due to no wear & tear
4, Low start-up wind speed-Means higher average power output
5, No rust - use Aluminum Alloy material, technical treatment by DACROMAT
6, No fade- after anti-oxidation treatment
7, Strong adaptability-means can be used for land, beaches, weak offshore wind
Regional power, lighting etc.
2. Feature:
Magnetic levitation technology Independent of the direction of the wind Startup at low wind speed of 1m/s Higher efficiency compared to traditional HAWT Works even in turbulence Visually pleasing appearance Turbine construction is resistant to gale 60m/s (132MPH) Robustness and adaptation to all possible environmental conditions thanks to material of aluminum alloy or stainless steel Design life: at least 20 years Noise: Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db3. Specifications
| Rated Power | 3000W |
| Size (Height / Diameter) | 3370/3700mm |
| Turbine Weight | 415 KG |
| Blades Material | Aluminum Alloy |
| Blades Qty. | 3 |
| Start-up Wind Speed | 1.5m/s |
| Cut-in Wind Speed | 3.5m/s |
| Rated Wind Speed | 13m/s |
| Cut out Wind Speed | 15m/s |
| Survival Wind Speed | 60m/s |
| Generator Type | 3 Phase AC |
| Controller Output Voltage | DC96V |
| Controller Output Current | <1300 Amp |
| Ambient Temperature | -40 ~ 50?℃ |
| Controller Braking System | 3 -Phase short circuit by NFB brake |
4.Application :
The practical appication of the maglev wind turbine as below:
1) Power supply for ships
2) Electricity for agriculture and fishery
3) Landscape education of wind energy and electricity
4) Wind-hydraulic generation system
5) Public electricity supply for building
6) Romote area
7) Independent house
8) Correspondence base
9) Street light
10) Electricity supply for community
11) Traffic signals
12) Independent military island
