PCB Drilling Motorized CNC High Speed Spindle 200000RPM PCB Spindle

Compatible H920B 200,000RPM CNC High Speed Spindle PCB Drilling

Quick Detail:

PRODUCT DESCRIPTION

MODEL:KL200B

REPLACE FOR:H920B

SPEED RANGE:20,000 - 200,000 rpm

BEARING TYPE:Air bearing

SPINDLE WEIGHT:3.5kg

COLLET SIZE:?1/8”

BODY SIZE: ? 61.9

Air Pressure:6.0 kgf/cm2

Max power:0.85KW

Fixed voltage:200V

Fixed current:3A

Static Runout:<2μm

Dynamic Runout:<7μm

Vibration:0.8MM/S

Competitive Advantage:

LOW STATIC

LOW DYNAMIC RUN OUT

STABLE CHARACTER AND LONG LIFE

SUITABLE FOR PRECISION DRILLING

APPLICATION :

PRINT CIRCUIT BOARD PRECISION DRILLING

HOLE RANGE: ?6.35mm-0.05mm

MACHINE REFERENCE:KLINGINBERG PLURITEC ；HITACHI ；LENZ ；ANDERSON ….

SPECIFICATION:

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Compatible H920B 200,000RPM 200B Spindle drawing

Why choose KLKJ?

With nearly 15 years technology in spindle maintenance, 10 years success experience for spindles parts production, and 9 years spindle R&D, KLKJ succeed in offer air bearing spindle up to 200krpm.

All spindles at the KLKJ are fully checked and tested using stringent quality control procedures. KLKJ ensures every repaired spindle passes the following points to make it in long life and stable character:

? ? ?7.? Static RUNOUT

? ? 8.? Dynamic RUNOUT

? ? 9.? Motor check

? ?10. Vibration

? ?11. Material analysis & strictly quality test detection control

? ?12. Stringent tolerance control
