Product Details

Brand Name	Glux		Place of Origin	China
Model Number	ODsn 6C

Product Description

Delivery Time:15-45 days (Depending on quantity)
Certification:CE ROSH

SMD 3-in-1 Outdoor Full Color? Curved LED Screen
?

Quick Detail:
?
1. Name:ODsn 6C
2. Pixel Pitch:6.2MM
3. Brightness:5000cd/m2
4. Recommended Viewing Distance:10-200m
5. Contrast:1500:1
6. Refresh Rate:600HZ
?

Description:
?
1. SMD 3-in-1 outdoor LED display
2. Carbon Fiber Materials for super light and thin structure
3. Angled edge structure for 90 degree curved assembly
4. Specific and targeted installation means fast steup and fast dismantling
5. Advanced pixel correction for the sharpest image quality
6. LCD info display:Indicating product peformance
?

Applicant:
?
Glux ODsn series suit for outdoor stage,outdoor advertisings and so on.
?

Specifications:
?
?

Glux LED Display ? ODsn Series	ODsn 6C	ODsn 8C	ODsn 10C	ODsn 15C
Pixel Pitch(mm)	6.2	7.8	10.4	15.6
Pixel Density(dots/m2)	25600	16384	9216	4096
Brightness(cd/m2)	5000	5000	5000	5000
Color Temperature(after calibration)K	6500	6500	6500	6500
Module Size(WHD)(mm)	50050045	50050045	50050045	50050045
Weight(kg/Panel)	3.5	3.5	3.5	3.5
Weight(kg/m2)	14	14	14	14
LED Type	3535 White	3535 White	3535 White	3535 White
LED Chip	MBI5020	MBI5020	MBI5020	MBI5020
Horizontal/Vertical Viewing Angle(o)	H160o/V160o	H160o/V160o	H160o/V160o	H160o/V160o
Recommended Viewing Distance(m)	10-200	10-200	10-200	10-200
Contrast	1500:1	1200:1	1000:1	1000:1
Refresh Rate(Hz)	600	600	600	600
Grey Scale(bit)	R’G’B’ 16bit	R’G’B 16bit	R’G’B’ 16bit	R’G’B 16bit
Frame Rate(Hz)	50/60	50/60	50/60	50/60
