Silent Operation Little Heat Generated Stage Led Screens 500mm x 500mm x 60mm

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	GLUX		Place of Origin	China
Model Number	SElf

Delivery Time:30 days (Depending on quantity)
Certification:CE,ROHS, UL

Silent Operation Little Heat Generated Stage Led Screens 500mm x 500mm x 60mm

Quick Detail:

1,Name :SElf 10

2,Pixel Pitch:10.41mm

3,Module Size:500*500*60mm

4,LED chip:Epistar

5,Refresh Rate:3000HZ

Description:

1,Press to Impress: Ideal for both indoor and outdoor applications of LED stage floors.

2,Die-cast aluminum modules can seamlessly create even largest floor configurations

3,DigiFloor modules are able to handle weights of up to a small car

4,Specialized filtering processes eliminate moire pattern(image artifacts)

5,16bit grey scale processing &pixel correction techniques ensure image quality

Applications:

SElf series suits for indoor and outdoor applications of led stage floors.

Specifications

Glux LED Display SEfl Series	SEfl6	SEfl10	SEfl20
Pixel Pitch(mm)	6.25	10.41	20.83
Pixel Density(dots/m2)	25600	9216	2304
Brightness(cd/m2)	5000	3000	1500
Color Temperature(after calibration)K	6500	6500	6500
Module Size(WHD)(mm)	50050060	50050060	50050060
Weight(kg/Panel)	8	8	8
Weight(kg/m2)	32	32	32
LED Type	SMD 3 in1	SMD3 in1	SMD 3 in i
LED Chip	Epistar	Epistar	Epistar
Horizontal/Vertical Viewing Angle(o)	H140/V140	H140/V140	H140/V140
Recommended Viewing Distance(m)	≥6	≥10	≥20
Contrast	2000:1	1500:1	1000:1
Refresh Rate(Hz)	1800	3000	8000
Grey Scale(bit)	R/G/B 12/16	R/G/B 12/16	R/G/B 12/16
Frame Rate(Hz)	50/60	50/60	50/60
Life Time(H)	≥50000	≥50000	≥50000
Protection	IP43/IP65	IP43/IP65	IP43/IP65
Power Supply	Dual Power Supply	Dual Power Supply	Dual Power Supply
Max Power Consumption(W/M2)	800	800	800
Avr Power Consumption (W/M2)	260	260	260
Working Temperature (℃)	-25-60	-25-60	-25-60
Working Humidity	10%-95%	10%-95%	10%-95%
Driving Method	1/5	1/3	Static
Cabinet Material	Aluminium alloy	Aluminium alloy	Aluminium alloy
Control Input	DVI/HDMI/HDSDI	DVI/HDMI/HDSDI	DVI/HDMI/HDSDI
Weight capacity(kg/m2)	≥10	≥10	≥10
