Product Details
| Brand Name | SADT | Place of Origin | China | |
| Model Number | HBRVU-187.5 |
Product Description
Certification:ＩＳＯ９００１
Accurate Bench Hardness Tester HBRVU-187.5?for Brinell Rockwell and Vickers Wide Measurement
T his tester is used for determining the Brinell, Rockwell and Vickers?hardness of ferrous, non-ferrous metals, hardmetals, carburized?layers and chemical treating layers. It can be applied in the factories,
scientific research institutes, laboratories and colleges.
Hardness tester HBRVU-187.5 serves the purpose of measuring the hardness of ferrous, non-ferrous metals, hardmetals, carburized layers and chemical treated layers.The Universal version enables the execution of Rockwell standard (150-60-100kgf) Brinell (31.25-62.5-187.5kgf) and Vickers tests(10-30-60-100kgf).The microscope together with the instrument allows fast and reliable measurements of Brinell and Vickers indentations both in the analogue and digital version.The digital version permits to determine the hardness value in the fast and easy way.
Specifications:
|
Preliminary test force(N)
|
98
|
Magnification of microscope×X
|
37.5X, 75X
|
|
Rockwell hardness test (N)
|
588, 980, 1471
|
Max height of speciments(mm)
|
200mm
|
|
Brinell hardness test (N)
|
306, 613, 1839
|
Max depth of speciments(mm)
|
200mm
|
|
Vickers hardn-ess test( N)
|
294, 980
|
Dimensions(mm)
|
546X300X767
|
|
Power Supply
|
AC220V 50/60Hz
|
Net weight(kg)
|
90
|
Packing List:
|
Accessory box of main body
|
1
|
Plastic anti-dust bag
|
1
|
|
Diamond Rocknell indenter
|
1
|
Certificate
|
1
|
|
Diamond Vickers indenter
|
1
|
Product operating manual
|
1
|
|
Φ 1.5875mm hardmetal ball indenter
|
1
|
Contrast sheef of metal Vickers Brinell hardness
|
1
|
|
Φ2.5mm, 5mm hardmetal ball indenter
|
1
|
Microscope seating
|
1
|
|
Standard Rockwell hardness block
|
3
|
15X micrometer eyepiece
|
1
|
|
Standard Vickers hardness block
|
1
|
2.5Xobjective
|
1
|
|
Standard Brinell hardness block
|
1
|
5Xobjective
|
1
|
|
Testing table(big, medium,\"V\")
|
1
|
Baffle testing table
|
1
|
|
Weight1,2,3,4
|
4
|
Vickers testing table
|
1
|
|
Weight 0
|
1
|
\"V\"testing table
|
1
|
|
Fuse 0.5A
|
2
|
Lamp adapter
|
1
|
|
6V-15F Lamp(6V/15W)
|
2
|
Chimnev
|
1
|
|
Power cord
|
1
|
Lamp (6V/15W)
|
1
|
