Home > Products > Ultrasonic Thickness Gauge > Integrtaed Ultrasonic Thickness Gauge QNix4200 /4500 Portable Digital Coating High Precision
Integrtaed Ultrasonic Thickness Gauge QNix4200 /4500 Portable Digital Coating High Precision
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Accuracy Portable Coating ultrasonic thickness tester with Digital LCD
-
Ultrasonic Thickness Gauge ST5900+ For metallic and nonmetallic materials
-
OLED digital Automatic Schmidt Test Hammer LED Display Data Software to PC
-
bridge concrete testing hammer , concrete rebound hammer for slab / beam / column
-
Ultrasonic coating thickness gauge , metal Ultrasonicthickness meter
-
Micro-Processor Ultrasonic Thickness Gauge SA50 For Coating 4 Digits LCD Display
Product Details
| Brand Name | SADT | Place of Origin | China | |
| Model Number | QNix4200 /4500 |
Product Description
Certification:ＣＥ ＩＳＯ９００１
Integrtaed Ultrasonic Thickness Gauge QNix4200 /4500?Portable Digital Coating High Precision
The QuaNix?4200 and QuaNix?4500 have been designed to meet the requirements of automotive and other painting applications.
The QuaNix?4500 measures over all metalls by just switching the mode from ferrous to non-ferrous or reverse. For those of you who only measure over steel or iron we have designed the QuaNix?4200.
?
Product Features
Execellent accuracy
One button only
Proven Hall Sensor Technology (and
eddy-current for QuaNix?4500)
One hand opperation
for all applications
Integrated sensors
without cable and connectors
Automatic switch on/off
Display in microns or mils
Acoustical signal
confirms measurement
| Substrate Steel and iron | Fe-probe (4200/4500) |
| Non-magnetic Metals,e.g. Aluminium, Copper, Brass | NFe-probe (4500) |
| Measuring Range | 0 – 999 μm |
| Accuracy | (2 μm + 3 % *) (*of reading) |
| Minimum Measuring Area | 10 x 10 mm |
| Minimum Curvature | 5 mm convex 25 mm concave |
| Minimum Substrate Thickness | Fe: 0,2 mm NFe: 0,05 mm |
| Temperature Range | 0 – 60°C |
| Display | Digital (LCD) |
| Probe | One Point (integrated) |
| Power Supply | 2 x 1,5 V Mignon Battery (alkaline) |
| Dimensions | 100 mm x 60 mm x 27 mm |
| Weight | ca. 110 g |
| Technical Data subject to changes without priov | ? |
