P2 Indoor High Definition LED Display Panel For Events Shows , High Contrast

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TeehoLED		Place of Origin	China
Model Number	CE, 3C , RoHS, ISO,FCC,UL

Product Description

Delivery Time:15-35days
Certification:CE,UL, ROHS, 3C, ISO,FCC

Quick Detail:
1. High definition
2. Good image quality
3. High brightness
4. Satisfactory after-sales
?

P2 Indoor High Definition LED Display Panel For Events Shows , High Contrast

?
Specifications:LED Specification

Part Number	Teeho-P2
Resolution	64(H)×32(V)
Pixel Pitch	2mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	250,000 pixels/ ㎡
Module Size	192*96mm
Driving IC	MBI5024
Driving Method	1/16 Scan, Constant Current
Screen Weight	30kg/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	1,800cd/ ㎡
View Angle	140°/140°
Gray Scale	8bits input, correction with 16 bits
Display COLOR	16.7M
Brightness Adjustment	0～100%
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	1300W/ ㎡
Average Power Consumption	450W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
Operating Life	100,000hours
MTBF	5000hours
Protection Level	～
Out of Control Rate	<0.02%

Description:
1.High Contrast:4000:1,which is a very high level to ensure a vivid image of our LED display screen system;
2.Clear vivid image quality even in direct,full-on sunlight to ensure you attracts more audience to get short ROI of your LED display screen\'s investment;
3.Long-term Brightness:7000-nit brightness(for outdor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen;
4.Easy Installation & Using:easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system ;
5. SMD display be an ideal advertising in all indoor advertising field.The viewing distance can be as short as 1 meters, as far as 200 meters, has a overwhelming advantage to LCD panels.
Applications:
Shopping malls
Supermarkets
Shopping centers
Public square
Super market
Competitive Advantage:
1. Perfect image quality;
2. High refresh rate;
3. Unique structure design;
4. Extreme viewing angle.
