SMD Indoor Full Color LED Display Screen With Lightweight Cabinet P7.62 , 17222 Pixels /
- T/T L/C D/P D/A
- 7 days
You May Like
-
Rental Full Color Indoor Advertising LED Display Screen 1R1G1B P7.62 , 1000Hz
-
Rental P10 LED Curtain Display Video P4.8 , Stage Background LED Display 10000 pixels /
-
P12.5 LED Color Display Screen For Stage , Large Screen Hire 3528 SMD 50mm
-
Synchronous P6 Rental LED Display Screen Wall IP43 , Stage Background LED Display
-
Indoor 1R1G1B Slim Rental LED Display For Television Relay , 3-IN-1 SMD P7.62
-
Super Slim P4 Rental LED Display Screen 8 Bit MBI5024 IP43 , LED Video Panel Rental
Product Details
| Brand Name | TeehoLED | Place of Origin | China | |
Product Description
Certification:CE, 3C , RoHS, ISO,FCC,UL
SMD Indoor Full Color LED Display Screen With Lightweight Cabinet P7.62 , 17222 Pixels / ㎡
Quick Detail:
1. High&low?brightness?recession?rate;?
2. Pure&rich?colors;?
3. Unique?mechanical?structure?design;?
4.Light?weight?cabinet & Fast?dismantle&installation;?
Description:
1. Wide application field & short ROI time；??
2. Clear vivid image quality:?Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen\'s investment；
3. Long-term Brightness:?7000-nit brightness (for outdoor full color)(2000 nits brightness for indoor full color ) capacity throughout product lifetime of the LED display screen；
4. Easy Installation & Using:?easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system；
5. Convenient Servicing:?Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.?
Applications:
???????????? Shopping Malls
???????????? Indoor advertising
??????????? ?Pub&club
???????????? Music Venues and Concerts
???????????? Car Shows
???????????? Airport
Specifications:
|
Part Number |
Teeho-p7.62 |
|
Resolution |
32(H)×16(V) |
|
Pixel Pitch |
7.62mm |
|
LED Configuration |
1R1G1B 3-IN-1 SMD |
|
Pixel Density |
17,222 pixels/ ㎡ |
|
Module Size |
244*122mm |
|
Driving IC |
MBI5024 |
|
Driving Method |
1/8 Scan, Constant Current |
|
Cabinet Weight |
42kg/sq.m. |
|
Mechanical Ratings |
|
|
Hanging Weight Support |
2T |
|
Surface Flatness |
Gap<0.5mm |
|
Optical Ratings |
|
|
Brightness |
>2,000cd/ ㎡ |
|
View Angle |
130°/120° |
|
Gray Scale |
8bits input, correction with 14bits |
|
Display COLOR |
16.7M |
|
Brightness Adjustment |
0～100% |
|
Power Supply |
|
|
Operation Power |
90～260V 50～60Hz |
|
Max. Power Consumption |
800W/ ㎡ |
|
Average Power Consumption |
200W/ ㎡ |
|
Control System |
|
|
Control Mode |
Synchronous display with control PC by DVI |
|
Frame Update Frequency |
60～85Hz |
|
Screen Refresh Frequency |
300～1000Hz |
|
Gamma Correction |
-5.0～+5.0 |
|
Support Input |
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
|
Control Distance |
Ethernet cable<120m or Fiber Optic<10Km |
|
Support VGA Mode |
1024×768, 1280×1024, 1600×1200, 1920×1280 |
|
Brightness Correction |
