High Contrast Outdoor Advertising LED Display P10 for Airport , IP65 1/4 Scan

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	GLIANG		Place of Origin	China
Model Number	GLIANG

Delivery Time:15days
Certification:CE, CCC, FCC, ROSH, ISO9001

Quick Detail:

1. 2 years warranty
2. Good consistency
3. Excellent visual effect
4. MBI5024 driving IC
?

High Contrast Outdoor Advertising LED Display P10 for Airport , IP65 1/4 Scan

Description:

1.Cabinet is stronger without distortion, anti-rust.

2.Synchronously adjust the brightness and color to make the true and exquisite image.

3.High contrast, high refresh rate make the image without any delay, trailing smear.

4.Special wooden box package production protect the whole screen system.

5.PCB patent technology, the most stable signal transmission technology in the world.

Applications:

??????????? Shopping malls??

???????????? postal offices

???????????? School

???????????? Monitoring

???????????? Restaurants

???????????? Entertainment

LED Specification

Part Number	TeehoLED-P10
Resolution	16(H)×16(V)
Pixel Pitch	10mm
LED Configuration	1R1G1B -DIP
Pixel Density	10,000 pixels/ m2
Module Size	160×160mm
Cabinet Size	960×960mm, 960×800mm, 800×800mm, etc.
Driving IC	MBI5024
Driving Method	1/4 Scan, Constant Current
Weight	58KG/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	7000CD
View Angle	120°/60°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Brightness Adjustment	0～100% 10 level
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	1000W/ m2
Average Power Consumption	320W/ m2
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature	-20°～+60°
Operating Humidity	10～95% RH
