2R1G1B P12 Outdoor Advertising LED Display Screens Illumination Lighting Panel
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
IP65 / IP54 Front maintenance P16 outdoor led illumination panel advertising screen
-
60HZ Indoor electronic led illumination panel display signs for advertising
-
Soundboss 1R1G1B DIP P10 outdoor led illumination panel display screen
-
Front Maintenance P20 Outdoor LED Screen Illumination Panel with CE & RoHS Approval
-
Outdoor Virtual LED Display Module (P16)
-
Outdoor LED Display Module P16
Product Details
| Brand Name | GLIANG | Place of Origin | China | |
| Model Number | GLIANG |
Product Description
Certification:CE, CCC, FCC, ROSH, ISO9001
2R1G1B P12 Outdoor Advertising LED Display Screens Illumination Lighting Panel
2011 Asian cup LED supplier
1.?36 months warranty. And life long free tech-support
2. CE and RoHS approval
3. Excellent contrast ratio, high resolution /high definition
4. High brightness and perfect uniformity
5.Waterproof IP65
Application:
Our products have been widely used in venues as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc;
Advantage:
1. Wide application & short ROI time:
Commercial advertising, Stadium perimeter, mobile media, shopping mall, bank & stock exchange, train & bus station, air port,
2. High Contrast ratio: 4000:1
This is a very high level to ensure a vivid image of our LED display screen system.
3. First-class LED chip:
Supplied by high strictly selected LED chip to ensure the long life time and high brightness of our LED display screen system
4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your investment.
5. Long-term Brightness:
6000 nit brightness capacity throughout product lifetime
|
SBO-P12 (Pitch 12mm outdoor full color) |
|
|
Colour temperature |
5000~9000 k |
|
Pixel structure |
Φ3 oval lamp, 2R1G1B |
|
Pixel pitch |
12mm |
|
Pixel density |
6, 944 dots/㎡ |
|
Luminance |
6, 000cd/㎡ |
|
Module dimension |
192mm(W) * 192mm(H) |
|
Module resolution |
16 pixel(W) * 16 pixel mm(H) |
|
Cabinet dimension |
1152 * 768mm |
|
Cabinet resolution |
96 * 64 |
|
Cabinet area |
0.885 sq. meter |
|
Optimal visual distance |
>10m |
|
Visual angel |
110 / 50 degree (H/V) |
|
Max power consumption |
≤960w / ㎡ |
|
Average power consumption |
≤450w / ㎡ |
|
Brightness adjustment |
Adjust according to the environment |
|
brightness software (0%-100%adjustable) |
|
|
Gray scale |
point by point 4096 gray grade levels of |
|
each color, 16 bits γ correction available |
|
|
Drive mode |
1/4 dynamic scan, constant current |
|
Frame frequency |
≥60HZ |
|
Refresh frequency |
≥1000HZ |
|
Input voltage |
AC 90~260 volts |
|
Operation temperature |
﹣40℃~ +65℃ |
|
Operation humidity |
10％～90％ |
|
Input signal |
S-video, RF, RGB, Yuv, YC, composite… |
|
Control system |
DVI card + master control card + receiver card |
|
MTBF |
>5000 hrs |
|
Life span (50% brightness) |
100, 000 hrs |
|
Malfunction dot rate |
