Mobile Office Containers - Modular, Galvanized Steel Structure, Wear Resistance Floor

Mobile Office Containers , Modular , Galvanized Steel Structure , Wear Resistance Floor

? Description:

Modular house as Waterproof, long-life span, environment-protection, flexible assembly/disassembly, stable prefabricated house.

It is easy of our products to install any size accommodation cabins for you, which could be used as parlor, bedroom, study, locker room, ablution room, shower room, kitchen and dining room.

Our product has the following advantages:

Advantage of Expansion: Cabins can be jointed in longitudinal and transverse directions without limits. They also enable stacking in 2 and 3 floors.

It’s convenient for folding. 7 units packed to one 40 HQ during delivery, so it is suitable for international transportation.???

Specifications of Each Unit:

I.?Dimension(mm)＆Weight(kg)

???L=6055mm, W=2435mm, H=2790mm

II. Steel Frame: Galvanized Steel Frame with Marine Paint Finishes?

??? Load bearing - floor load: max. load capacity 2.0 kN/m2 (200 kg/m2)

??? Capacity?- wind load: 25 m/s (90 km/h)

III.?Wall : 50 - 100mm thick Sandwiched Panel?

IV.?Insulation : 50-100mm thick Rockwool or Neopor EPS

V. Door: 900 x 2100 mm Alum. Frame Metal Door or PVC Door

VI. Windows: 800 x 1000 mm Alum. Frame or PVC Window

Competitive Advantage:

Knock-down Panel wall saves transport and storage space

Top and bottom are pre-assembled in the factory in order to minimize the on-site work

With firm structure, the earthquakes and typhoons can be resisted

With the insulation material of rock wool and Noepor polystyrene, good fireproof performance is available.

Modular design, be linked on unlimited extension

Easy to be repaired and maintained for high standardization.

Life time 30 years.
