Prefab Container House for Cold Area - 100mm Thick Wall, Heat Conduction Cut-off

Prefab Container House for Cold Area, 100mm Thick Wall with?Heat Conduction Cut-off, PVC Window

Description:

This is a standard single container house for cold area. Thickness of wall increases to 100mm with Nylon strip to cut off heat conduction. Small porch between main door and bedroom door can stop cold are go direct to room when main door is opened.

The overall size of a standard single container house is 2.4m*6m.The containers can be stacked each other to three floors and be jointed in longitudinal and transverse directions without limits. You can combine them yourself to achieve specific requirement.

Cabin is consisted of ready-made floor frame, roof frame, wall panels, internal partitions and accessories. 2 workers can assemble on basic unit within 4 hours (about 14.4 square meters). It’s convenient for folding. 4 units packed to one 20 feet container during delivery, so it is suitable for international transportation.???

Applications:It has various functions for different usage, such as temporary office or dormitory, working camp living building and residential building etc.

Specifications:

I.?Dimension(mm)＆Weight(kg)

???L=6055mm, W=2435mm, H=2790mm

II. Steel Frame: Galvanized Steel Frame with Marine Paint Finishes?

???Load bearing - floor load: max. load capacity 2.0 kN/m2 (200 kg/m2)

???Capacity?- wind load: 25 m/s (90 km/h)

III.?Wall : 50 - 100mm thick Sandwiched Panel?

IV.?Insulation : 50-100mm thick Rockwool or Neopor EPS

V. Door: 900 x 2100 mm Alum. Frame Metal Door or PVC Door

VI. Windows: 800 x 1100 mm Alum. Frame or PVC Window

Competitive Advantage:

Knock-down Panel wall saves transport and storage space

Top and bottom are pre-assembled in the factory in order to minimize the on-site work

With firm structure, the earthquakes and typhoons can be resisted

With the insulation material of rock wool and Noepor polystyrene, good fireproof performance is available.

Modular design, be linked on unlimited extension

Easy to be repaired and maintained for high standardization.

Life time 30 years.

Layout:
