Movable Foldable Container for Exhibitions Modular, Mobile, Environmental Protection

Item

Name

Specs and Data

Basic Specs

Length

Length of modular: 6055mm; Combined building Length: N*6055

(N＝2,3,4……)

Width

Width of modular: 2435mm; Combined building width: N*2435

(N＝2,3,4……)

Height

2790mm, Max 3 floors

Standard Items

Base Frame

Main beam 4mm special profile,Q235

Roof Frame

Main beam 3mm special profile, Q235

Column

Column 3mm special profile, Q235

Rain Water System

Concealed gutter, discharge from rainwater down pipe

(concealed in column)

Wall Panel

50, 75, 100mm Sandwich Panel

Roof Panel

0.45mm Colorbond metal sheet

Ceiling

10mm Laminated timber board

Floor

18mm Plywood with 2mm thick floor vinyl sheet

Door

Alum frame insulated metal door, size: 800mm*2100mm

Window

PVC swing window,size: 800mm*1100mm

Lights

2*40w double tube fluorescent light, 2 sets

Switch

1 set

Socket

16A socket for A/C, 1 no; 10A Socket, 3 nos.

DB

40A

Optional Items

Ventilation

Fan

40w Fan

Floor Finishes

Ceramic tile, PVC floor board, Laminated timber parquet

Partition

50mm thick sandwiched panel

Structure Data

Roof live load

50kg/m2

Floor live load

200kg/m2

Wind load

0.45KN/m2

Earthquake Intensity

8 degree
