JZC350 Concrete Mixer

JZC350 Concrete Mixer

Product Introduction

JZC350 Concrete mixer

JZC 350 Diesel Engine Powered Concrete Mixer with Hydraulic Tipping Hopper is mixer of double conical drums which discharge concrete by reverse-rotation, suitable for mixing plastic and semi-dry & hard concrete with the size of aggregate up to60mm. Mixing is carried out when the mixing drum rotates in normal direction, and discharge is performed when the mixing drum rotates in reversed direction. Each time, the mixing drum can handle 0.35 cubic meters of concrete.

It is suitable in construction site ,roads ,bridges and other place.

This series concrete mixer is to mix for converse and discharge for reverse, which may mix plasticity and semi-rigid concrete. Its advantage has sooth working, convenient operation, good mixing quality and high productivity, ect. And it is the ideal machines for construction fields, road, bridge project and all kinds of concrete parts factory. JZC series mixer includes JZC200, 250, 350, 500, 750 and JZM350. All the machines are portable type except JZC750 is stationary one.

Main Parameter

Type JZC350
Discharging Capability          L         350
Charging Capability             L                      560
Productivity                     m3/h                      12-14
Power of Mixing  Diesel Engine    HP              15
Power of Pump Electrical Motor     kW 0.55
Dimension(L×W×H)           mm 2760×2140×3170
Total Weigh                       kg 2300
