Solid Coil Winding Electronic Wire Tensioner With 5m / s METSS

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

KIMCHEN

Place of Origin

China

Product Description

Delivery Time:3 to 5 working days
Design: Compact?and?Solid Electronic Tensioner RM Series electronic tension device Coil Winding Electronic Tensioner
?

Solid Coil Winding Electronic Wire Tensioner With 5m / s METSS
?

Place?of?Origin:	Dong?Guan?China
Brand?Name:	KIMCHEN
Model:	MET?Series
Feature:	Control?System?are?packed?within?the?body
Design:	Compact?and?Solid
Tension?test?condition:	Wire?speeding?5m/s?refer?roundness?Bobbin
Power:	DC24V
Electric?Current:	1.2A
Product?Size:	140mm140mm45mm
Weight:	0.56KG

Detailed Product Description:

MET Series Electronic Tensioner is by integrating the electronic system and non-contact breaking design, there is barely any contact in the core mechanism of the main tension, wheel, except the connecting bearing .This combination provide smooth, stable and consistence tension, even in high speed winding. The non contact designs also reduce wear and tear of most of the critical components as to cut down maintenance cost. All MET comes with “ Auto Tension Fine Tuning System”. By sensing the movement of the tension arm, the control system will fine tuning the tension automatically.
Control system are packed within the body.

MET Series is solid and compact in design. It operates with DC24V electronic power.
MET Series also comes with wire jump prevention and wire breakage detection.

MET Electronic Tensioner Specifications

?

Model	Tension?Range?(g)	Applied?wire?diamiter(mm)
METSS	3　－　15	φ0.02－φ0.04
METS	5?。?0	φ0.03－φ0.09
METM	50?。?40	φ0.08－φ0.20
