Coil Winding Servo Wire Tensioner With Cylinder , Tension Roller

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KIMCHEN		Place of Origin	China
Model Number	SET-BR Series

Product Description

Delivery Time:7 to 10 working days
?Coil?winding?tensioner ?coil?winder?tensioner ?coil?winding?tension?Unit ?coil?winding?wire?tensioner

Coil Winding Servo Wire Tensioner With Cylinder , Tension Roller SET-100-BR
?

Model:	SET-BR?Series
Characteristic:	With?Cylinder?inside
Tension?roller?is?fixed?in?front?of?tensioner
Function:	Can?change?over?two?tension?forces
Power:	DC24V
Electric?Current:	1.2A
Insert?Air?Pressure:	5kg/cm2
Wire?speeding:	5m/s
Product?Size:	300mm215mm115mm

Detailed Product Description:

SET-BR Series Servo Tensioner With Cylinder Inside

　　SET-BR Series Servo Tensioner is with Cylinder inside and the tension roller is fixed in front of tensioner body. It is able to changing-over two tension forces.

Servo tensioner is sent from the traditional passive-line change to take the initiative to send lines from the motor, by replacing the spring tension to change its value, this product comes with tension feedback stabilization system that can automatically tension stable equilibrium. Tension is not speed, wire cover, pulleys, and felt the impact of tension in particular stable and easy to adjust.

The linear speed of standard type is 5m/s, and it can be customized that according to your special requirements.
?

Specifications:
?

Model	Applied?wire?diamiter(mm)	Tension?scope(g.f)
SET-100-BR	φ0.01—φ0.12	1g—100
SET-200-BR	φ0.02—φ0.17	2g—200
SET-300-BR	φ0.03—φ0.22	5g—300
SET-500-BR	φ0.05—φ0.32	20g—500
SET-600-BR	φ0.06—φ0.35	20g—600
