Home > Products > Servo Wire Tensioner > DC24V Coil Winding Servo Tensioner With Cylinder SET-200-BR
DC24V Coil Winding Servo Tensioner With Cylinder SET-200-BR
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
5m / s Coil Winding Servo Wire Tensioner With 0.01 - 0.12 mm SET-100
-
DC24V Coil Winding Servo Wire Tensioner with Motor SET-100-R
-
Coil Winding Servo Wire Tensioner With Cylinder SETA-100-R
-
DC24V Coil Winding Servo Wire Tensioner with Motor SET-300-R
-
1.2A Coil Winding Servo Wire Tensioner With 0.02 - 0.17mm SET-200-R
-
High Speed Servo Wire Tensioner For Coil Winding Machine SET-2000-R
Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
| Model Number | SET-BR Series |
Product Description
?Coil?winding?tensioner ?coil?winder?tensioner ?coil?winding?tension?Unit ?coil?winding?wire?tensioner
DC24V Coil Winding Servo Tensioner With Cylinder SET-200-BR
?
|
Model: |
SET-BR?Series |
|
Characteristic: |
With?Cylinder?inside |
|
Tension?roller?is?fixed?in?front?of?tensioner |
|
|
Function: |
Can?change?over?two?tension?forces |
|
Power: |
DC24V |
|
Electric?Current: |
1.2A |
|
Insert?Air?Pressure: |
5kg/cm2 |
|
Wire?speeding: |
5m/s |
|
Product?Size: |
300mm*215mm*115mm |
Detailed Product Description:
SET-BR Series Servo Tensioner With Cylinder Inside
SET-BR Series Servo Tensioner is with Cylinder inside and the tension roller is fixed in front of tensioner body. It is able to changing-over two tension forces.
Servo tensioner is sent from the traditional passive-line change to take the initiative to send lines from the motor, by replacing the spring tension to change its value, this product comes with tension feedback stabilization system that can automatically tension stable equilibrium. Tension is not speed, wire cover, pulleys, and felt the impact of tension in particular stable and easy to adjust.
The linear speed of standard type is 5m/s, and it can be customized that according to your special requirements.
?
Specifications:
?
|
Model |
Applied?wire?diamiter(mm) |
Tension?scope(g.f) |
|
SET-100-BR |
φ0.01—φ0.12 |
1g—100 |
|
SET-200-BR |
φ0.02—φ0.17 |
2g—200 |
|
SET-300-BR |
φ0.03—φ0.22 |
5g—300 |
|
SET-500-BR |
φ0.05—φ0.32 |
20g—500 |
|
SET-600-BR |
φ0.06—φ0.35 |
20g—600 |
