DC24V Servo Wire Tensioner With 0.05 - 0.32mm Wire Diamiter SET-500-BR
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
1.2A Servo Wire Tensioner For Toroidal Coil Winder SET-300-BR
-
DC24V Servo Wire Tensioner With 0.02 - 0.17mm SET-200-BR
-
Coil Winding Servo Wire Tensioner With Cylinder , Tension Roller
-
Servo Wire Tensioner With 5g - 300 g.f For Coil Winding Machine
-
5m / s Coil Winding Servo Wire Tensioner With Tension Roller SET-200-B
-
Custom Coil Winding Servo Wire Tensioner With 1g - 100g.f SET-100-B
Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
Product Description
Coil Winding Tensioner coil?winding?tension?Unit coil?winding?wire?tensioner Servo Tensioner
?
DC24V Servo Wire Tensioner With φ0.05 - φ0.32mm Wire Diamiter SET-500-BR
?
|
Model: |
SET-BR?Series |
|
Characteristic: |
With?Cylinder?inside |
|
Tension?roller?is?fixed?in?front?of?tensioner |
|
|
Function: |
Can?change?over?two?tension?forces |
|
Power: |
DC24V |
|
Electric?Current: |
1.2A |
|
Insert?Air?Pressure: |
5kg/cm2 |
|
Wire?speeding: |
5m/s |
|
Product?Size: |
300mm*215mm*115mm |
Detailed Product Description:
SET-BR Series Servo Tensioner With Cylinder Inside
SET-BR Series Servo Tensioner is with Cylinder inside and the tension roller is fixed in front of tensioner body. It is able to changing-over two tension forces.
Servo tensioner is sent from the traditional passive-line change to take the initiative to send lines from the motor, by replacing the spring tension to change its value, this product comes with tension feedback stabilization system that can automatically tension stable equilibrium. Tension is not speed, wire cover, pulleys, and felt the impact of tension in particular stable and easy to adjust.
The linear speed of standard type is 5m/s, and it can be customized that according to your special requirements.
?
Specifications:
?
|
Model |
Applied?wire?diamiter(mm) |
Tension?scope(g.f) |
|
SET-100-BR |
φ0.01—φ0.12 |
1g—100 |
|
SET-200-BR |
φ0.02—φ0.17 |
2g—200 |
|
SET-300-BR |
φ0.03—φ0.22 |
5g—300 |
|
SET-500-BR |
φ0.05—φ0.32 |
20g—500 |
|
SET-600-BR |
φ0.06—φ0.35 |
20g—600 |
