MT-30 Coil Winding Mechanical Wire Tensioner For Tension Control
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom Coil Winding Mechanical Wire Tensioner with 5m / s
-
YZ2S Mechanical Wire Tensioner With 9g - 50g Tension Scope
-
Coil Winding Mechanical Wire Tensioner For Nittoku Winding Machine
-
002 - 004mm Coil Winder Mechanical Wire Tension YZ3S
-
Mechanical Wire tensioner With 20g - 140g Tension Scope YZS
-
YZ2M Mechanical Wire Tensioner For Nittoku Winding Machine
Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
Product Description
Application:Winding?machine Function:Tension?Control wire tensioner magnetic wire tensioner
MT-30 Coil Winding Mechanical Wire Tensioner For Tension Control
?
|
Place?of?Origin: |
Dong?Guan?China |
|
Brand?Name: |
KIMCHEN |
|
Model: |
MT?Series |
|
Tension?test?condition: |
Wire?speeding?5m/s?refer?roundness?Bobbin |
|
Application: |
Winding?machine |
|
Function: |
Tension?Control |
|
Product?Size: |
170mm*100mm*60mm |
|
Weight: |
0.41KG |
Detailed Product Description:
MT Series Horizontal Type Magnetic Tensioner is used on coil winding machine by using permanent magnet, tension is generated to the damp wheel. The non-contact mechanism design provides stable, consistence and precision tension to the wire. Excellence for both high and normal speed winding.
?
|
Model |
Applied?wire?diamiter(mm) |
Tension?scope(g.f) |
|
MT-30 |
φ0.02-φ0.06 |
3-30 |
|
MT-100 |
φ0.04-φ0.12 |
10-100 |
|
MT-200 |
φ0.06-φ0.16 |
20-200 |
|
MT-400 |
φ0.08-φ0.25 |
50-400 |
|
MT-600 |
φ0.12-φ0.35 |
80-600 |
|
MT-800 |
φ0.14-φ0.40 |
100-800 |
