2.5 " 1Ch 2G / 3G Mobile DVR Security Systems with 1 Ethernet, 1RS232, 1RS485 port

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Zhengqi

Place of Origin

China

Product Description

Delivery Time:5--7work days after receive your payments

2.5 \" 1Ch? 2G / 3G Mobile DVR Security Systems with 1 Ethernet, 1RS232, 1RS485 port

Descriptions

VC-MDR700X Mobile DVR adopt highly integrated H.264 ASIC, its image quality is excellent, in addition to using the hard disk as a video storage medium or it can use SD card as an auxiliary video storage medium to improve the stability of record data. Through the built-in USB port the video data can be backed up quickly.

VC-MDR700X In addition to integrated vehicle status monitor, it can support built-in GPS, 2G/3G modules.

The playback software of MDR700X can not only achieve the synchronous and asynchronous multi-channel playback, the video and GPS also enables synchronization of data such as playback, convenient video analysis.

VC-MDR700X can be widely used in buses, taxis, police cars, law enforcement vehicles, and other various types of vehicles.
?

Key Features

H.264 Compression, Record Resolution Up to D1 Dual Stream for Recording and Network transmit Support Hard disk and SD card recording, USB and Network Backup Pluggable hard disk 2.5 \" HDD tray, with mature vibration reduction technology Independent 6 Vehicle status monitor interface, of which one can speed 8-32V power input Vent-free enclosure design

Specifications
Model	VC-MDR7001	VC-MDR7002	VC-MDR7004
Video Input	1 Ch	2 Ch	4Ch
Video Input Parameter	1.0Vp-p, 75 Ohms, ? Aviation plug
Video ??Output	1 Ch
Video Output? Parameter	1.0Vp-p, 75 Ohms, ? Aviation plug
Video ??Compression	H.264
Preview ?Resolution	D1 resolution(PAL:704×576, NTSC:704×480)
Dual Stream-Main	30FPS@D1(NTSC) 25FPS@D1(PAL)	60FPS@D1(NTSC) 50FPS@D1(PAL)	120FPS@CIF(NTSC) 100FPS@CIF(PAL)
Dual Stream-Aux	30FPS@CIF(NTSC) 25FPS@CIF(PAL)	60FPS@CIF(NTSC) 50FPS@CIF (PAL)	30FPS@CIF(NTSC) 25FPS@CIF(PAL)
Record Resolution	D1	D1	CIF
Dual Stream Network transmission	Independent? 4CIF(HA-01D/02D Only), CIF/QCIF
Playback Frame rate	PAL:1～25 fps , NTSC:1～30 fps
Record band rate	16K～2Madjustable, Customizable (unit:bps)
Audio Input	1Ch	2Ch	4Ch
Audio Input Parameter	2Vp-p Line, 1OK Ohm , Shard the? Aviation plug with video input
Audio Output	1Ch
Audio Output Parameter	3Vp-p, 600ohms, Shard the? Aviation plug with video output
Built-in 2G/3G module	Optional
Built-in GPS Module	Optional
