PAL 25fps NTSC 30fps 4 Channel H.264 High Profile 3G Mobile DVR with GPS for Bus Security
- T/T L/C D/P D/A
- 7 days
You May Like
-
1 / 2 / 4 CH Video GPS WIFI HDD SD 3G Vehicle Mobile Security DVR For Car Black Box Camera
-
1 - 4 Channels G.726, 5KB/S GPS SD 3G Mobile Car DVR With CIF, HD1, D1 Resolution
-
4 Channel H.264 D1 SD Vehicle 3G Mobile Security DVR Built - In GPS, 2G / 3G Modules
-
H.264 ASIC 3G SD Mobile DVR For Car Black Box Camera With 4 Channels Alarm Input for Vans
-
PAL And NTSC 4 CH Audio And Video SD Mobile DVR with RS485 Control for Trains Security
-
H.264 Full D - 1 Resolution NTSC 30pfs / PAL 25fps SD Mobile DVR Systems 1 / 2 / 4 channel
Product Details
| Brand Name | Zhengqi | Place of Origin | China | |
Product Description
PAL 25fps NTSC 30fps 4 Channel H.264 High Profile 3G Mobile DVR with GPS for Bus Security
Descriptions
This Mobile DVR is mounted on a small, rugged, vibration and shock resistant bracket, allows recorded video to be quickly exported through it’s an extra USB2.0 HDD Reader.
This Mobile DVR supports ?1 or 4 channels of video, 1 channels of audio and gives users the option of selecting recording resolutions from CIF(352x288) to D1 (704x576). The removable hard drive stores recorded video and can be removed and connected to a standard PC to view recorded video. It supports 3G and GPS function . This mobile solution comes complete with everything required for simple installation.
This mobile solutions are currently being used in the following applications:
Law Enforcement - Patrol Cars Military - Tanks Emergency – Ambulances, Fire Trucks Public – Buses, Trains, Railways, Subways Commercial – Boats, Heavy Equipment, Limousines, Taxis, Vans Transportation - Freight LinersAviation – Helicopters, Commercial and Private Aircraft
Specifications
|
Item |
Parameter |
Description |
|
System |
Language |
Chinse Simplified/Chinese Traditional/English/other language order |
|
Interface |
Graphical User Interface |
|
|
Security |
Administor and user password protected |
|
|
Video |
Video Input |
4 channel video input, 1.0V, p-p, 75Ω |
|
Video Output |
1 channel vidoe output, 1.0V, p-p, 75Ω |
|
|
Display |
1/4 channel display |
|
|
Video Standard |
PAL (25fps) NTSC (30fps) |
|
|
Audio |
Audio Input |
1 channel audio input, 20KΩ |
|
Audio Output |
1 channel audio output, 500Ω |
|
|
Output level |
1V ~2V, p-p |
|
|
Recording mode |
Audio and video simultaneously recording |
|
|
Compression |
AAC |
|
|
Storage |
Video Compression |
H.264 High Profile |
|
Video bitrate |
D1: 200Kbps ~ 2Mbps, 3 selectable quality |
|
|
Audio bitrate |
8KB/s(Compressed) |
|
|
Storage |
2.5 inch hard disk |
|
|
Alarm |
Alarms |
1-4 CH |
|
Communication |
COM |
one RS232 connector for optional |
|
GPS |
Support external GPS module, geographic coordinates, speed can be written in code stream |
|
|
G-SENSOR |
Support |
|
|
3G |
Support EVDO/WCDMA/CDMA2000 for optional |
|
|
Firmware update |
Via USB disk |
|
|
Power |
Power input |
DC:+8V ~ +32V |
|
Power output |
