Compact design underground heating and cooling system(5.8Kw~59.5Kw)

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Taiyu

Place of Origin

China

Delivery Time:10-15 days after receiving TT payment
Certification:CE / EN14511

Hermetic?scroll?type Compact design underground? source heating and cooling system (5.8Kw~59.5Kw)

Specifications

1.Outlet water max 60 degrees
2.The use of all-weather
3.Easy installation, low noise
4.For cooling,heating,hot water

Features:

1.30?–?50%?reduction?in?CO2?emissions

2.Fully-automatic?electronic?control?and?long-lasting?components

3.Hermetic?scroll?type?compressor?pumps?refrigerant?

4.Environmentally-friendly?and?safety?refrigerant?R410a.

5.Structure?and?base?in?hot?galvanized?epoxy?powder?coated?steel

6.Exchangers?plant?side?plate?of?stainless?steel?AISI?316

7.High?and?low?pressure?switches?protect?the?system?and?vital?components

8.Compact?design?and?extremely?quite?operation.

Parameter:

Model	?	BHP-W20/RM
Heating Capactiy(B0/W35)	kw	22.5
Power Input(B0/W35)	kw	5.05
COP(B0/W35)	w/w	4.46
Water flow Rate(Utility side exchanger)	l/s	0.6
Heating Capactiy(B0/W45)	kw	31.7
Power Input(B0/W45)	kw	8.93
COP(B0/W45)	w/w	3.55
Water flow Rate(Utility side exchanger)	l/s	0.9
Heating Capactiy(B0/W55)	kw	28.5
Power Input(B0/W55)	kw	10.52
COP(B0/W55)	w/w	2.71
Water flow Rate(Utility side exchanger)	l/s	0.9
Cooling Capacity(B35/W18)	kw	29.5
Power Input(B35/W18)	kw	7.95
EER(B35/W18)	w/w	3.71
Water flow Rate(Utility side exchanger)	l/s	1.8
Cooling Capacity(B35/W7)	kw	25
Power Input(B35/W7)	kw	7.74
EER(B35/W7)	w/w	3.23
Water flow Rate(Utility side exchanger)	l/s	1.8
Max output temp.heating medium	°C	60
Operating temp.heating medium	°C	0
Power Supply	V/P/Hz	380/3/50
Compressor Type	Type	Scroll
NO.Compressor	Pcs	1
Refrigerant	Type	R410a
Utility side heat exchanger	Type	plate heat exchanger
Source side heat exchanger	Type	plate heat exchanger
Noise	dB(A)	≤50
Water connection	inch/mm	1.2/30.5
Water-Proof grade	Type	IPX4
Weight	kg	142
Dimension	mm	950×620×1150
