1.05 W Copper 1.25Gb/s Fiber SFP Module 1000 BASE-T With SGMII Interface
- T/T L/C D/P D/A
- 7 days
You May Like
-
T x 1550nm - R x 1310nm 20km 1.25Gbps / 1.063Gbps Bi-Directional SFP Transceiver Module
-
10 / 100 / 1000Mbps Copper Fiber SFP Transceiver Module For 1.25 Gigabit Ethernet
-
Bi-Directional 1.25G T x 1490nm - R x 1310nm 20km Fiber Optical SFP Transceiver Module
-
Duplex LC Connector 1.25Gbps 850nm GE SFP Transceiver Module GLC-SX-MM
-
TRx 850nm 1.25Gbps SFP Transceiver Module With 300m / 550m Transmission
-
3.3V Single Power Router / Server Interface 1.25G TR x1310nm 20km SFP Transceiver Module
Product Details
| Brand Name | Rollball | Place of Origin | China | |
| Model Number | GLC-T |
Product Description
Certification:FCC, CE, RoHS
1.05 W Copper 1.25Gb/s Fiber SFP Modules 1000 BASE-T With SGMII Interface
Features
l?Up?to?1.25Gb/s?bi-directional?data?links
l?Hot-pluggable?SFP?footprint
l?Extended?case?temperature?range?(0°C?to?+70°C?)
l?Fully?metallic?enclosure?for?low?EMI
l?Low?power?dissipation?(1.05?W?typical)
l?Compact?RJ-45?connector?assembly
l?Access?to?physical?layer?IC?via?2-wire?serial?bus
l?1000?BASE-T?operation?in?host?systems?with?SERDES?interface
l?10/100/1000Mbps?compliant?in?host?systems?with?SGMII?interface
Applications
l?1.25?Gigabit?Ethernet?over?Cat?5?cable
DescriptionRollball’s GLC-T Copper Small Form Pluggable (SFP)transceivers is high performance, cost effective module compliant with the Gigabit Ethernet and 1000- BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supp- orting 1000Mbps data- rate up to 100 meters reach over unshielded twisted-pair category 5 cable. The module supports1000 Mbps full duplex data-links with 5-level Pulse Amplitude Modulation (PAM) signals. All four pairs in the cable are used with symbol rate at 250Mbps on each pair. The module provides standard serial ID information compliant with SFP MSA, which can be accessed with address of A0h via the 2wire serial CMOS EEPROM protocol. The physical IC can also be accessed via 2wire serial bus at address ACh.
Specification:
|
General |
||||||
|
Parameter |
Symbol |
Min |
Typ |
Max |
Units |
Notes/Conditions |
|
Data?Rate |
BR |
10 |
1,000 |
Mb/sec |
IEEE?802.3?compatible. See?Notes?2?through?4?below |
|
|
Cable?Length |
L |
100 |
m |
Category?5?UTP.?BER?<10-12 |
Notes:
1. Clock tolerance is 50 ppm
2. By default, the GLC-T is a full duplex device in preferred master mode
3. Automatic crossover detection is enabled. External crossover cable is not required
4. 1000 BASE-T operation requires the host system to have an SGMII interface with no clocks, and the module PHY to be configured per Application Note AN-2036. With a SERDES that does not support SGMII, the module will operate at 1000BASE-T only.
