Trenchless Horizontal Directional Drilling

Horizontal Directional Drilling

Horizontal directional drilling is not digging the ground surface conditions, the laying of a variety of underground utilities (pipelines, cables, etc.) of a construction machinery, it is widely used in water supply, electricity, telecommunications, natural gas, coal gas and oil pipelines and other municipal laying construction for sand, clay, gravel, etc. conditions, most non-hard rock areas can be construction. Horizontal directional drilling technology is the oil industry directional drilling technology and the traditional pipeline construction methods combined with the construction of a new technology, it has the speed of construction, the construction of high precision, low cost, without damaging the environment and so on. Our advanced horizontal directional drilling performance, high efficiency, ease of operation, key components of international support, is ideal for construction equipment.

Model XZ680
Project
 Unit
 Parameter

Engine
 Factory

 Chongqing Cummins

Model

 NTA855-C335

Rated Power
 kW / rpm
 250/2100

Push-pull
 Type

 Four + four motor-driven rack and pinion gear

Biggest pullback / feed force
 kN
 680/680

Power head speed
 m / min
 0 ~ 23

Rotation
 Type

 Dual-motor drive gear

Maximum torque power head
 N.m
 27000

Power head speed
 r / min
 0 ~ 100

Diameter
 mm
 φ102

Length (single)
 m
 6

Rigs
 Type

 Sliding box rigs, away platen

Adjusting the angle
 °
 10 ~ 18

Crane
 Type

 Full rotary telescopic crane arm

Maximum lift quality
 t
 2

Travel drive
 Type

 Steel tracked self-propelled

Walking speed
 km / h
 2.5

Mud




Flow
 L / min
 600

Cab

 Single

Dimensions
 mm
 11000 × 2800 × 3300

Weight
 t
 22
