Common glavanized barbed wire machine and razor barbed type

FOB Price

USD $3,580 - $4,680 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	TOPS
Model Number	CS-A,CS-B,CS-C	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Common glavanized barbed wire machine and razor barbed type

There are three types of barbed wire machines for your choice:

CS-A Type:Single wire

The materials used are general hot dipped galvanized

,low carbon steel wire and plastic coated wire.

The products are widely used in national defense, railway, highway, agriculture, animal husbandry and other industries.

Main parameters:

No.	Item	Units	Parameters
1	Motor power	KW	3
2	Main drive shaft speed	r/min	402
3	Strand wire diameter	mm	2.2-3.0
4	Barbed wire diameter	mm	1.8-2.2
5	Barb distance	Mm	76(3”) 102(4”) 127(5”)
6	Twist number	Pcs	3.5
7	Theoretical output	Kg/h	70
8	Total weight	Kg	1200
9	Dimension of main part	mm	19509501300
10	Dimension of take-twisting part	mm	1760550760

Note: Special specification models can be customized according to customer requirements.

CS-B Type :Double Wire

The materials used are general hot-dipped galvanized low carbon steel wire and low-strength steel wire. Main feature: saving materials.

Main parameters:

Loading and packing:

Note: Special specification models can be customized according to customer requirements.

After-sales service:

Maintenance period:one year
If the buyers need, we can send our technical staff to the buyer's factory to install and

debug the machine, training is also available. But the buyer need to in charge of the fees

, such as the round air ticket, salary, meals and accommodation and so on.
