Metal Chips Compactor
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Jinall | |
| Model Number | SBJ-1500 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
metal chips compactor1.normal pressure:1225KN
2.size of briquetteaa:80x(50-70)mm
3.weight of briquette:2-2.5kg
SBJ-1500 metal chips compactor
Technical Parameter
This machine is used for cold pressing of other metal scraps including powdery grainy cast iron scrap aluminium scrap, copper scrap and steel scrap etc. To coumniform caky block with the density >=5.5t/m3 (without any bond).
After out of the furnace, the caky block can be used as pig iron. This machine is designed with quick speed cylinder and liquid rinsing valve. The B type machine has auto charging unit which can be operated by singal man. With the novel particular sturcture, and national patent this machine is original in China.
Model | SBJ-1500 |
Normal pressure(kn) | 1225KN |
Inner diameter of main cyclinder (mm) | Φ250 |
Size of briquetee(mm) | Φ80x(50~70) |
Density(t/m3) | ≥4.8 |
Weight of briquetee(kg) | 2~2.5 |
Productivity (block/min) | 3 |
Output in one shift(Ton) | 2~2.5 |
Total Power(kw) | 15 |
Weight(kgs) | 3000 |
Dimension(mm) | 2100x1400x2000 |
