Leadshine 57HBM20-1000 - 2.0 N.m (283 Oz-In) 3 Phase NEMA 23 Easy Servo Motor With 1000-Line Encoder
- 1000 Piece / Pieces per Month
- Shenzhen Guangzhou Shanghai Qingdao Ningbo and so on
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Leadshine motor 2 phase 2.2NM 57HS22 + M542 Leadshine 2 phase stepper Driver New
-
Leadshine motor 2 phase 1.3NM 57HS13 + M542 Leadshine 2 phase stepper Driver New
-
Leadshine motor 2 phase 0.9NM 57HS09 + M542 Leadshine 2 phase stepper Driver New
-
Leadshine 57HS22-A 2-phase Hybrid Step Stepper Motor 81mm long 1.8 step angle 2.2NM
-
Leadshine 57HS22 2-phase Hybrid Step Stepper Motor 81mm long 1.8 step 2.2NM
-
Leadshine 57HS13 2-phase Hybrid Step Stepper Motor 76mm long 1.8 step 1.3NM
Product Details
| Place of Origin | Guangdong, China | Brand Name | Leadshine | |
| Model Number | 57HBM20-1000 |
Product Description
Features
3 phase
NEMA 23 frame size
2.0 Nm (283 oz-in) holding torque
Speed range: 0 - 3,000 RPM
Integrated 1,000-line incremental encoder
Smooth movement
Low motor heating and noise
57HBM20-1000 is 2.0 Nm (283 oz-in) 3-phase NEMA 23 stepper motor with integrated 1,000-line incremental encoder. It is built with high quality material and can move smoothly with high precision, very low noise & heating.
When driven by Leadshine 57HBM20-1000 easy servo drive, the position loop between the motor and drive is fully closed. Therefore, loss of steps which limits adoption of stepper systems is totally eliminated. Because there is no torque resolution needed like in open loop stepper systems, you can much better high-speed performance than open loop stepper systems by increasing up to 30%. Such systems are also ideal to replace brushless servo systems to offer huge starting and low speed torques. You can get more information on Leadshine Easy servo Products page.
Leadshine 57HBM20-1000 easy servo motor can also be driven by regular open loop 3-phase stepper drives, and output encoder signals to motion controllers, or external devices.
