Home > Products > motor and driver > M542 stepper motor driver for laser engraving and cutting machine
M542 stepper motor driver for laser engraving and cutting machine
- 500 Set / Sets per Month
- shenzhen shanghai guangzhou
- Credit Card PayPal
You May Like
-
leishine motor and driver for co2 laser engraving and cutting machine
-
co2 laser laser motor and driver
-
stepper motor for laser engraving and cutting machine
-
57hs22 and driver M542, stepper motor for laser engraving and cutting machine
-
3 phase stepper motor driver 3nd583
-
Cost-effective 3 phase laser stepper driver 3nd583
Product Details
| Place of Origin | Guangdong, China | Brand Name | leishine | |
| Model Number | m542 | Phase | 2 | |
| Type | Variable Reluctance | Certification | CE | |
| Current / Phase | 4.2A |
Product Description
M542 -2 phase Analog stepper motor . Max 50VDC/ 4.2A
Feature
1 .Extremely cost-effective
2.Good high speed performance
3.Supply voltage up to +50 VDC
4. Output current up to 4.2A
5.Self-adjustment technology
6.Pure-sinusoidal current control technology
7.Pulse input frequency up to 300 KHz
8.TTL compatible and optically isolated input
9.Automatic idle-current reduction
10. 15 selectable resolutions in decimal and binary, up to 25,600 steps/rev
11 .Suitable for 2-phase and 4-phase motors
- 12. Support PUL/DIR and CW/CCW modes
- 13. Short-voltage, over-voltage, over-current protections
Description
The M542 V2.0 is a high performance microstepping drive based on pure-sinusoidal current control technology. Owing to the above technology and the self-adjustment technology (self-adjust current control parameters) according to different motors, the driven motors can run with smaller noise, lower heating, smoother movement and have better performances at higher speed than most of the drives in the markets. It is suitable for driving 2-phase and 4-phase hybrid stepping motors.
More other leishine stepper motor and driver please feel free to contact me .
