4*2 Dongfeng 5m3 Truck Mounted Water Well Drilling Rig for Sale
- Any port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Fire Department Pumper Connection Fire Fighting Truck Price With 6000Kg Fire Truck Water Capacity
-
HOWO 6*4 Fire-extinguishing Foam Tanker With Crane Wrecker
-
Chinese Hot Sale Fire Fighting Truck Price
-
HOWO 6*4 Water Tanker Emergency Rescue Crane Wrecker Fire Truck
-
Sinotruk HOWO 6*4 Water Tanker Emergency Rescue Fire Fighting Truck
-
Chinese Famous Manufacture 17ton Water Tanker With All Capacity For Sale
Product Details
| Condition | New | Transmission Type | Manual | |
| Emission Standard | Euro 3 | Fuel Type | Diesel | |
| Dimensions (L x W x H) (mm) | 7000*2180*2480 | Gross Vehicle Weight | 9400 | |
| Place of Origin | Hubei, China | Brand Name | Dongfeng | |
| Model Number | EQ1090T9A12419-TWW |
Product Description
4*2 Dongfeng 5m3 Small High Pressure Cleaning Truck
High Pressure Cleaning Truck , is also called High Pressure Spraying Truck ,sidewalk cleaning truck, mainly used in cleaning road, sidewalk, guardrail, silt, stubborn stains, health corner and other kinds of public facilities. It has many kinds of features: large flow , high pressure , cleaning conveniently, saving water etc.
Production Notes:
1.High pressure cleaning truck is a multifunctional vehicle for dredging and cleaning the drainage block the city underground sewers ,the contamination blocked in pipes and the sludge sediments in the ditch,etc. And it also could be used for cleaning the industrial pipes, walls and furthermore acts as a sprinkler, water transportation. Moreover, could be equipped for fire fighting.
2.It could be added sprinkling device,garden sprinkle apparatus for front swashing, rear spilling, side spraying, used to water garden, spay, dust catch and clean the street road.
3. Flow large, high pressure ,saving water ,low price
Main Technical Parameters | |||
Product Name | 4*2 Dongfeng 5m3 Truck Mounted Water Well Drilling Rig | Gross Weight (kg) | 9400 |
Overall Dimension(mm) | 7000×2180×2480 | Related Payload(kg) | 4600 |
Tank Dimension(mm) (L*L axle *S axle) | 2900*1800*1300 | Curb Weight (kg) | 4605 |
Wheelbase (mm) | 3800 | Number of Axles | 2 |
F/R Suspension(mm) | 1180/2020 | F/R axle load(Kg) | 3460/5940 |
Appr/Dep Angle(º) | 22/10 | Max Speed(km/h) | 90 |
Cab Allowed Persons | 3 | Cab type | DFAC DLK yellow cab |
Chassis | |||
Chassis Model | EQ1090T9ADJ3AC | Chassis Manufacturer | Dongfeng Automobile Co., Ltd |
Gear Box | 5 speed forward and 1 reverse | Transmission type | Manual |
Steering Type | LHD(Power steering) | Brake System | Air brake |
Leaf Spring No. | 11/9+7,8/10+7 | Front/Rear tread(mm) | 1831 /1640 |
Drive Type | 4x 2 | Tire Spec. | 7.50-16 |
Engine | |||
Engine Model | CY4102-E3C | Engine Brand | Dongfeng Chaoyang |
Fuel Type | Diesel | Emission Standard | Euro 3 |
Displacement ( ml ) | 3856 | Power (KW) | 91(120hp) |
Superstructure equipment | |||
Tank Material | 4mm Carbon steel | High Pressure pump | Imported Italy pump |
Flow(L/Min) | 125L/min | Pump pressure | 16MPa |
Equipped with 60m long Diameter 19mm high pressure pipe, 10 high pressure sprayers | |||
Production Feature | High pressure, saving water, high efficiency | ||
Warranty | 12 months, from the date of supply | ||

--- Packing: Waxed or nude, and covered with tarpaulin.
--- Shipping: small type can be shipped in 20"GP,40"GP,or 40"HQ, big type can be
shipped in bulk ship or RO-ROshipping, or according to your requirement.
CLW GROUP
ChengLi Special Automobile Co.,Ltd, is the headquarter of CLW GROUP. We are the biggest manufacture of Special Purpose Vehicles in Suizhou city. And Suizhou city is the biggest Chinese production base of special purpose vehicles.
CLW is our trademark. As the biggest manufacture in Suizhou city, we have been awarded many honors, for example, CLW Group is the 19th in the top 100 private enterprises in Hubei province. CLW Group is also 500 private enterprises in China."High-tech enterprises in Hubei province", " Best credit enterprises".CLW sprinkler truck was named "Hubei famous brand"; "CLW" won the Hubei famous brand, A Well-Known Trademark in China.
Our leading products include Water truck, Fire truck, Garbage truck, LPG vessel/truck/trailer, Refrigerator truck, Dump truck, Concrete mixer truck , Sewage truck, Crane Truck, Van truck, etc.
With high quality and low price, our products are widely exported to Africa, Asia and South America every year.
1. The total assets of CLW Group is 300,000,000 USD.
2. Our headquarter covers an area of more than 200 acres.
3. We have more than 8000 employees, of which more than 500 technical engineers,
more than 2000 technical workers.
4. Our annual production capacity is 100,000 sets of special vehicles.
5. We have more than 2000 sets of large production equipment, more than 200 sets
of testing equipment, some of which the machining centers and production lines are
in the world leading level.
6. We have more than 100 independent innovation products obtained national patent,
the vehicle type sewage purification device, gas lighting fire trucks and other projects
to get third-prize progress of science and technology.
7. More than 840 CLW brand products are included in the national bulletin directory.
1.You are factory or trading Company?
We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2.Could you customize exactly according to my requirements?
Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
3. Do you provide certification that we need?
We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
4. What service can I get from you?
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
