Stainless Steel Wire Drawing Machine
US$ 100,000 - 250,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T
You May Like
Product Details
| Inlet Diameter | 4-6.5mm | |||
| Outlet Diameter | 0.8-1.6mm | Place of Origin | Jiangsu, China | |
| Brand Name | wanyi | Model Number | LZ(Straight line) | |
| Voltage | 220V and 380V | Power(W) | 1X22+18.5X8KW | |
| Dimension(L*W*H) | 9X1.5X1.5M | Weight | 16 Tons | |
| Certification | CE SGS CIQ, CE ISO | Warranty | one or two year | |
| After-sales Service Provided | Overseas service center available |
Product Description
| Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
| Reel diameter | mm | 900 | 800 | 700 | 560 | 400 |
| Draw passage | time | 9-12 | 10 | 9 | 10 | 10 |
| Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 |
| Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 |
| Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 |
| Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
| Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 |
| Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-20.02 | 18.61-16.74 |
| Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
