Bull Block Wire Drawing Machine

5.Electrical configuration and control performance

5.1. Electric control and allocation The system adopt AC variable frequency speed regulating, PLC

control+field bus technology+color touch screen, deploy control cabinet,master operational console.

5.1.1. Motor : Siemens &ABB

5.1.2. Converter : LS.

5.1.3. PLC : Siemens S7-300

5.1.4. Master operation Touch screen Monitor: Taiwan

5.1.5. Master operation operating function: power on, outage, machine start, machine stop, speed up,

meter, set length, set speed, set full scale, full scale direction and restoration. Converter failure and restoration, malfunction search, production data statistics, emergency shut down etc.

5.1.6. transducer use imported high precision Non-contact displacement transducer,Siemens

5.1.7. low voltage electrical apparatus element :Schneider

5.1.8. LED signal lamp. Red stay lit: normal stop,Red flicker: failure warning, Green stay lit :

normal working, Yellow flicker: full scale automatic stop.

6. Machine color

Main color is Green. The door color is yellow, or as  per  your requirements.

7. Installation and Commissioning

7.1. First party should finish installation well , drainage system, water supply, air delivery pipe port.

7.2. We take charge install machine and test run. Your side take charge machine debugging.

7.3. Power:380±10%,50HZ, three phase.

7.4. Air supply:≥0.5MPa ,

7.5. Cooling water: ≥0.2 MPa, Water temperature≤30℃

7.6. Technicians from the seller will be on site the workshop of the Buyer for the installation

instruction and commissioning. The cost of the engineers for the commissioning should be on the buyer side including the round-trip flight tickets, insurance, food and lodging. The buyer pay the salary during the commissioning.The buyer should have interpreter on site for the commissioning

8. Warranty:

One year freely.Warranty for parts for manufacturing defects, or damage incurred by seller’s technicians during commissioning,for one years period from the date of commissioning except damage caused by accident or abnormal operation and consumable parts.
