FY830-A Horizontal internal broaching machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port shenzhen
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangxi, China	Brand Name	XiaShi
Model Number	FY830-A	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Introduction

This machine adopts the principle of hydraulic transmission, through usIing the fluid pressure energy to transfer thedynamic,and atopt action element to transfer liquid pressure energy into mechanical energy, which drives the workpiece cutting broach. Broaching is stable, can be stepless speed regulation, rapid return to help you improve production efficiency. Handle control can operate through half cycle or whole cycle . The track after high frequency annealing the coated hard layer, it is difficult to wear, than the average service life of the machine tool was increased several fold. The use of simple repair, particularly suitable for mass production. Has the advantages of high precision, high efficiency, low noise etc. direct manufacturers absolute low price affordable.

Main uses: irregular holes machining hole, slot, involute, square hole, six angle hole, spline, half round, and other various geometries.

Technical parameters

Model	FY830-A	FY830-JC	FY840-A
Rated tension	300KN	300KN	400KN
Broaching stroke	1500mm	1700mm	1500mm
Motor power	7.5kw	7.5kw	11kw
Worktable pore diameter	130mm	130mm	150mm
Boraching speed	20-25min/m	20-27min/m	20-25min/m
Return speed	8-10min/m	9-11min/m	8-10min/m
Machine weight	2300kg	2300kg	2300kg
Machine overal dimension (LWH)	4200530910mm	4500530910mm	4200530910mm

Picture details

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
