China factory CNC slotting machine for metal processing BK5032E BK5040E

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Power Source	Hydraulic	Place of Origin	Zhejiang, China
Model Number	BK5032E BK5040E	Voltage	380V/220V Optional
Power(W)	3kw	Weight	2700kg
Dimension(LWH)	2000x1500x2500mm	Certification	CE ISO
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Machine Main Function

1. It adopt mechanical transmission and stable working.

2. It’s easy operation with circulatory and adjustable working mode.

3. It adopt Taiwan ballscrew and KND K2000 CNC system to realize longitudinal,horizontal and rotary numerical control.

Technical parameter

Specification	XSBK5032E	Unit
CNC system	K2000
RAM travel	320	mm
Worktable longitudinal movement distance (X axis travel)	560	mm
Worktable horizontal movement distance	540	mm
Y axis rotation angle	0-360	°
Max. cutting force	8	KN
Distance from tool head support surface to front wallof machine bed	600	mm
Worktable diameter	630	mm
RAM angle of inclination	0-8	°
RAM vertical adjustable distance	370	mm
Distance from worktable surface to carriage bottom	455	mm
Install cutter edge size	25*40	mm
Worktable max. load capacity	500	kg
Worktable center T-slot width	18H8	mm
Main motor power	3	KW
Rapid motor power (about)	0.75	KW
Machine weight (about)	2700	kg
Overall dimension	2000×1500×2500	mm
