Top China Hoston ZK3020L multi spindle CNC Drilling Machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port shenzhen
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Drilling Speed	Optional	Place of Origin	Zhejiang, China
Brand Name	XiaShi	Model Number	ZK3020L
Voltage	380v/50Hz	Power(W)	3.2kW
Dimension(LWH)	1360x1350x1880 (mm)	Weight	1200KG)
Certification	CE,ISO	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

multi spindle CNC Drilling Machine
1.Portable drilling machine
2.Vertical drilling machine
3.Ample rigidity and long service

HOSTON multi spindle CNC Drilling Machine

Characters

♦ With Max.spindle speed up to 40000r/min, wide speed range, the machine can be applied in the processing of nonferrous metals such as Zinc, Aluminum, Copper, as well as Resin Matrix Composite meterials.

♦ Window type parameterized CNC system gathers modules of processing of common thread. The CNC system is convenient to operate and program, meanwhile, G-code programming can also be adopted to meet the requirment from different user.

♦ CNC cross slide table with high positioning accuracy and fast moving speed, which can be applied in the processing of components with multi threads or these with high requirment in thread distance, such as the processing of strainer in food machinery.

Specifications:

Model			ZK3020L
Moving	X-axis travel	mm	300
	Y-axis travel	mm	180
	Z-axis travel	mm	300
	Distance between spindle end and table	mm	40~340
	Distance between spindle center and column surface	mm	255
Table	Table size	mm	500x200
	T-slot(aide x number x space)	mm	12x3x63
	Allowable load	kg	50
Spindle	Motor of spindle	kW	0.4
	Speed of spindle	r/min	10000-40000
	Taper of spindle nose	/	ER16
Feed	Motor of X,Y axis	N.m	2.4
	Motor of Z axis	N.m	7
	Rapid feed rate	m/min	25
	Cutting feed rate	m/min	1.5
Accuracy	Positioning accuracy	mm	0.03
Accuracy	Repeat ability	mm	0.02
Other	Power requirement	kW	3.2
	Overall size	m	1.36x1.35x1.88
	N.W	kg	1200
	Type of cover		Totally enclosed guard

Detailed pictures for your reference

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
