Portable CNC flame cutting machine

FOB Price

USD $100 - $10,000 / Set

1 Set(Min.Order)

Port Shenzhen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Yunnan, China
Brand Name	XIASHI	Model Number	HD-1020
Voltage	220V	Rated Power	220W
Dimension(LWH)	250027360	Weight	120kg
Certification	CE & ISO9001	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

This machine with a large gantry CNC cutting machine, like any complex parts can be cut.

Host vertical and horizontal rails are made of imported dual-axis precision linear guide, linear degrees, and walking stability, high accuracy.

Can cut any complex plane figure, for better oxygen gas flame cutting, plasma cutting machine, free moving, does not occupy a fixed site.

Affordable, practical and suitable for self-employed, small-scale manufacturing and light industrial machinery and other industries.

Technical Parameters

HD Portable NC Flame/Plasma Cutting Machine
Model	HD-1020	HD-1225	HD-1530	HD-1560
Power source	220±10%VAC 50/60Hz 220W
Cutting mode	O2/C3H8or C2H2, Plasma available
Effective cutting range(mm)	1000×2000	1200×2500	1500×3000	1500×6000
Track L×W×H(mm)	2500×273×60	3000×273×60	3500×273×60	7000×273×60
Track Holder Quantity	2	3	3	6
Track Holder L×W×H(mm)	500×80×40
Cutting speed(mm/min)	0-3500 (Max 4000 available)
Cutting thickness(Flame)(mm)	5-150(O2/C3H8or C2H2)
Cutting thickness(Plasma)(mm)	In terms of plasma power source
Move precision	±0.2mm/m
Torch	Flame,electric height adjustment(±60mm)
Host weight(kg)	19
Total weight(kg)	120	130	140	220
Gas pressure(Mpa)	Max0.1
Oxygen pressure(Mpa)	Max0.7
Type of gas	Propane, Ethine
Emergency stop	Yes
Working temperature	-5~45℃
Relative humidity	<95% No condensing
Standard configuration is 2#propane cutting nozzle if no special requirement.
Tailor-made track if request.

Detailed pictures for your reference

2.If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
