Home > Products > Plastic Valves > U-PVC Angle Seat Valve
U-PVC Angle Seat Valve
Negotiable
/ Carton
5 Cartons(Min. Order)
- Shanghai/Ningbo
- T/T
You May Like
-
U-PVC Female Threaded Single Union Spring Foot Check Valve
-
U-PVC Single Union Spring Foot Check Valve
-
U-PVC One Side Female Threaded Other Side Male Threaded Single Union Spring Check Valve
-
U-PVC One Side Side Threaded Single Union Spring Check Valve
-
U-PVC Foot Spring Check Valve
-
U-PVC Both Side Female Threaded Ball Check Valve
Product Details
| Material | Other, UPVC, UPVC | Type | Other, Valves | |
| Place of Origin | Zhejiang, China | Model Number | DIN | |
| Brand Name | TU | Connection | Female |
Product Description
Dia | DN mm | D mm | L mm | L1 mm | L2 mm | H mm | Kg/PCS | Box/Pcs | PN | EPDM O-RING CODE |
20 | 15 | 43 | 124 | 130 | 28 | 65 | 0.132 | 1 | 16 | 222 00 020 4 |
25 | 20 | 47 | 144 | 150 | 37 | 75 | 0.200 | 1 | 16 | 222 00 025 4 |
32 | 25 | 56 | 154 | 160 | 37 | 90 | 0.323 | 1 | 16 | 222 00 032 4 |
40 | 32 | 64 | 174 | 180 | 44 | 102 | 0.498 | 1 | 16 | 222 00 040 4 |
50 | 40 | 82 | 194 | 200 | 48 | 123 | 0.860 | 1 | 16 | 222 00 050 4 |
63 | 50 | 95 | 224 | 230 | 60 | 144 | 1.455 | 1 | 16 | 222 00 063 4 |
75 | 65 | 92 | 284 | 290 | 74 | 186 | 2.499 | 1 | 16 | 222 00 075 4 |
90 | 80 | 104 | 300 | 310 | 85 | 204 | 3.511 | 1 | 16 | 222 00 090 4 |
