YP-Q45 28Khz Ultrasonic Cutter
- Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Other, ultrasonic cutting machine | |
| Application | PC Board,Natural Fibre,Artificial Fibre,Thin Artificial Resins | Place of Origin | Zhejiang, China | |
| Brand Name | FYCG | Model Number | YP-Q45 | |
| Rated Power | 200 W | Dimensions | design as you want | |
| Voltage | 220 V | Power(W) | 200 W | |
| Certification | CE ISO 9001:2008 | After-sales Service Provided | Overseas third-party support available |
Product Description
YP-Q45 28Khz Ultrasonic Cutter
Applications
| Detailed Design Work | Printed Circuit Boards | Film Material and Fabric | Other cuts |
 | | | |
Easily cuts openings in plastic products or removes burrs or rough edges. Makes clean, even cuts through rubber or Styrofoam. | Makes precise cuts into patterns and printed circuit boards. Perfect for quick and accurate corrections. | Cuts synthetic and composite materials without fraying. Easily cuts aluminum and cork sheets. | The YP-Q45 can be used in a wide range of applications such as cutting paper, wood, food products, plaster, cable or in building scale models and other small detailed items. |
Features
Compact Design:
The handle, oscillator, foot switch, cord, and other components all fit into a compact aluminum case. This makes the YP-Q45 easy to carry and easy to store. The handle is light and easy to grip,enhancing operating ease.
Clean Cut:
The tip of the blade generates 22,000 ultrasonic vibrations per second during cutting.
However, the operator does not feel any vibration as the YP-Q45 accurately follows the cut line
and effortlessly produces a clean, even cut.
Easy Operation:
Simply turn on the switch and begin cutting. No other adjustments are necessary.Even a first-time operator can use it with ease.
Safe And Economical:
Oscillation of the blade is turned on or off by the foot switch. This means that booth hands can be used for safe cutting control. And the responsive switch helps conserve electrical power, boosting economical operation.
EXAMPLES OF USE (time will depend on specific material. Values in the table are just for reference) |
| Time to cut 3cm | Using YP-Q45 | Standard Cutter |
| Material | Thickness | Time(Seconds) | Material | Thickness | Time (Seconds) |
| Plastic Model | 1 mm | 2 | Leather Belt/Jacket | 1.5 mm | 8 |
| Plastic Model | 3 mm | 4 | Leather Suede type | 2 mm | 16 |
| Acrylic | 1 mm | 4 | Rubber Sticky/Viscous | 1 mm | 2 |
| Acrylic | 5 mm | 15 | Rubber Sticky/Viscous | 3 mm | 4 |
| PVC | 1 mm | 1 | Rubber Sticky/Viscous | 5 mm | 6 |
| PVC | 10 mm | 7 | Rubber CR (Polychloropren) | 1 mm | 3 |
| Polypropylene | 0.5 mm | 2 | Rubber CR (Polychloropren) | 3 mm | 3 |
| Teflon Tube | 1 mm | 2 | Rubber CR (Polychloropren) | 5 mm | 11 |
| Duracon | 5 mm | 2 | Butyl Rubber | 10 mm | 5 |
| Cardboard | 5 mm | 2 | Rubber NR *Natural Rubber) | 1 mm | 2 |
| Ice Cube | 2 mm | 2 | Rubber NR (Natural Rubber) | 8 mm | 4 |
