Home > Products > farm machinery > Wood Briquette Charcoal Production Line With Big Capacity
Wood Briquette Charcoal Production Line With Big Capacity
- qingdao/ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | SAIYE | |
| Model Number | JXI-1 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
wood briquette charcoal production line with big capacity
I .charcoal machine
1. Crushing---à2.drying--à 3.briquetting-à4.Carbonizing --à5.Packing
Crusher:
Model | JXI-1 |
Productivity (kg/h) | 500-600kg/h |
The diameter of the material (mm) | ≤ø150-200 |
The biggest diameter (mm) | Ø5*5 |
Motor power(kw) | 7.5kw |
Net weight | 350-500kg |
The wood dryer:
Power | 4 KW |
Output | 300-400KG/H |
Diameter of raw materials | <3mm & < 5mm |
Temperature of Hot Air | 180°C~250°C |
Consumption of Wood Waste | 30-35KG/H |
Dimension | Square stove: 1.5x1.06x1.1m 800kg/740kg |
Pipe : 2.44x1.22x1.55m 300kg/260kg | |
Net/Gross Weight | 1000/1100kg |
Briquette Extruder Machine
Model No. | ZBAI-101A | ZBAI-102A |
Productivity | 120-200 kg/h | 250-300 kg/h |
Motor power | 11kw | 15kw -18.5kw |
Motor power | 3*1.5kw | 3*1.5kw |
Weight | 600kg | 700kg |
Size outside | 1860*700*1260mm | 1860*750*1360mm |
Carbonization furnace
Model | SYTL-3 |
power | 4kw |
Output | 500-600kg/stove |
dimension | 2550*1820*2100mm |
G/N weight | 4500/4000kg |
Package machine
Model | SYAM-4035 |
Motor Power | 5 kw |
Max Packing Size | 400 * 350 |
Outer Size | 1200 *780 *550 mm |
Application material | PVC , POF , PP etc. |
