Rectificadora / Small Cylindrical Grinder / Cylindrical Grinding Machine
Negotiable
/ Set
1 Set(Min. Order)
- China Port
- T/T
You May Like
-
CNC Camshaft Grinding Machine ( Special-use Crankshaft Grinder Machine)
-
Oilstone Super Finishing Machine
-
High Precision Abrasive Belt Polishing Machine for Cam Shaft
-
CNC Horizontal Shaft Round Worktable Surface Grinder
-
Cam Shaft Belt Polishing Machine (Metal Burnishing Machine)
-
BGK-500 Large-size High Speed CNC Cylindrical Grinding Machine
Product Details
| Condition | New | Type | Cylindrical Grinding Machine | |
| CNC or Not | Normal | Max. Grinding Diameter | 320mm | |
| Max. Grinding Length | 500-3000mm | Brand Name | TIMAC | |
| Model Number | G-200,G-320,G-320A | Voltage | as customer's request | |
| Power(W) | 5.5KW | Dimension(L*W*H) | 260/300*203*205 | |
| Weight | 4000KG | Certification | CE & ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
"5-320mm" Small External Cylindrical Grinder/Grinding Machine
Product Description
Standard Accessories:
Coolant tank, wheel periphery dresser base(without diamond pen), flange and wheel extractor, Standard grinding wheel, Balancing arbor, Working lamb, Leveling edge, Open steady rest, Operation manual(English edution).
Optional Accessories:
Balance stand, Magnetic separator apparatus, Paper filter appparatus, Center grinding attachment, Close steady rest, End wheel dresser, Radius wheel dresser.
Parameter:
| Specification | Unit | G-200 | G-320 |
| *General capacity | |||
| Distance between centers | mm | 500, 750 | 1000, 1500, 2000, 3000 |
| Center height | mm | 135 | 180 |
| Dia.Ground (O.D) | mm | 5-200 | 8-320 |
| Max.Length ground(O.D) | mm | 500, 750 | 1000, 1500, 2000, 3000 |
| Max.Weight of workpiee | kg | 100 | 150 |
| * Work head | |||
| Center taper (MT) | MT | 4 | 5 |
| Spindle speed | r/min | 50HZ:25-380 Stepless | 26, 52, 90, 130, 180, 260 |
| * Wheel head | |||
| Wheel spindle speed | r/min | 1335 | 1100 |
| Wheelhead rapid travel | mm | 50 | 50 |
| Max. travel | mm | 205 | 235 |
| Hand feed per.rev | mm | rough:2, fine:0.5 | rough:2, fine:0.5 |
| Hand feed per.gra | mm | rough:0.01, fine:0.0025 | rough:0.01, fine:0.0025 |
| Wheel size (ODXWXID) | mm | 500x50x203 | 600x63x305 |
| Peripheral velocity | m/s | 35 | 35 |
| * Table | |||
| Hand feed per.rev | mm | 6 | 6 |
| Longitudinal speed range of table | m/min | 0.1-4 | 0.1-4 |
| * Tailstock | |||
| Center taper (MT) | MT | 4 | 4 |
| Quill travel | mm | 30 | 30 |
| * Motor | |||
| Wheelhead motor power | kw | 5.5 | 11 |
| Workhead motor power | kw | 0.75 | 0.75/1.5 |
| * Machine | |||
| Gross weight | T | 4 (500), 4.2 (750) | 5.3 (1000), 6.1 (1500), 7.9 (2000), 9.9 (3000) |
