CNC vertical machining center (VMC)
- 100 Set / Sets per Month
- China port
- T/T
You May Like
Product Details
| Condition | New | Type | Vertical | |
| Brand Name | TIMAC | Model Number | VM650, VM800, VM1100 |
Product Description
CNC Vertical Machining Center (VMC)
Features:
1. With high speed, accuracy and rigidity as well as temperature stable increasing spindle system.
2. Super grade lubricationg grease for spindle bearings ensures its long service life.
3. Spindle hole is equipped with air-blowing devce for cleaning.
4. Rectangular guide ways of X,Y and Z axes with good resistance against vibration and impact are suitable for heavy load cutting, finish and rough machining.
5. Adequate workpiece cooling system.
Specification | VM650 | VM800 | VM1100 | |
Travel | ||||
X travel | 600mm | 800 mm | 1100 mm | |
Y travel | 400 mm | 450 mm | 550 mm | |
Z travel | 500 mm | 550 mm | 600 mm | |
Distance between spindle center and column guide way | 450 mm | 550 mm | 610 mm | |
Distance between spindle end and table | 138-648 mm | 150~700 mm | 150~750 mm | |
Table | ||||
Table size | 800×400 mm | 950×460 mm | 1200×580 mm | |
Max. table load | 500kg | 600kg | 800kg | |
T-slot(width×number×space) | 18×3×135mm | 18×3×150mm | 18×5×120mm | |
Spindle | ||||
Taper bore of spindle | BT40 | |||
Spindle speed | 60-8000rpm | |||
Main motor power | 7.5/11KW | 7.5/11KW | 11/15KW | |
Cutter removal from spindle | Pneumatic | Pneumatic | Pneumatic | |
Feel | ||||
X,Y travel speed | 0-12m/min | 0-16m/min | 0-20m/min | |
Z travel speed | 0-12m/min | 0-16m/min | 0-20m/min | |
X,Y,Z Motor torque | 12Nm | 12Nm | 22Nm | |
Repeatability(X/Y/Z) | ±0.003 mm | ±0.003 mm | ±0.003 mm | |
Tool changing system | ||||
Tool number | vertical type: 16 | vertical type: 24 | ||
Max. tool size | Ø85 mm(vertical type) | Ø80 mm(vertical type) | ||
Max. tool size | Ø130 mm(vertical type) | Ø130 mm(vertical type) Ø150mm(horizontal type) | ||
Max. tool length | 350mm(vertical type) | 300mm(vertical type) | ||
Max. tool weight | 8kg(vertical type) | 7kg(vertical type) | ||
Tool changing time(cut to cut) | 2s(vertical type) | |||
Other | ||||
Min. Input(X/Y/Z) | 0.001 mm | |||
Overall dimensions(L×W×H) | 2280×1880×2100 m | 2400×2110×2800 mm | 2900×2350×2900 m | |
Net weight | 4500kg | 5000kg | 7000kg | |
