VERTICAL MACHINING CENTER
- 300 Set / Sets per Month
- China port
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Brand Name | TIMEWAY | |
| Model Number | VMC714 | Dimension(L*W*H) | 2120X2150X2290mm | |
| Weight | 3450kg | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
VERTICAL MACHINING CENTER
Feature:
• FANUC 0i mate-MD CNC system
with RS232 I/O interface;
• High precision and speed spindle unit;
• 16 station Auto.tool magazine(Taiwan);
• Electronic hand wheel (MPG);
• Totally enclosed work space;
• Auto central lubricating;
• Work light; Tricolor alarm light
• Operating tools; Operation manuals.
• Solid cast-iron machine body;
• High quality linear guide ways on all axes
Optional accessories:
• CNC controller
-- FANUC 0i MD
-- KND 2000M
-- GSK 983M
• The Forth axis
• Automatic chip conveyor
.
Specification | Unit | VMC714 |
Table travel | mm | 650 x 400 x 500 |
Table size | mm | 900 x 400 |
Number/width/distance | mm | 3-18-130 |
Max.load of table | kg | 400 |
Distance fromspindle to table surface | mm | 120-620 |
Distance from soindle axis to vertical guideway | mm | 510 |
Rapid feed speed | m/min | 24 |
Feed speed | mm/min | 2.5-4000 |
Spindle taper |
| BT40 |
Spindle speed range | r.p.m | 40-6000 |
Spindle motor power | kw | (AC servo) 5.5 |
Tool magazine capacity | qty | 16 |
Max.weight of tool | kg | 8 |
Max.dimension of tool | mm | 120X200 |
Positioning accuuracy | mm | 0.015 |
Repeat positioning accuracy | mm | 0.0075 |
Min.time of tool change | sec | 7 |
Overall dimension | mm | 2120X2150X2290 |
N.W. | kg | 3450 |
