CMPA601C025F Description High Efficiency GaN HEMT MMIC From 6 GHz to 12 GHz

CMPA601C025F  Description High Efficiency GaN HEMT MMIC from 6 GHz to 12 GHz

In May 2015, Cree announced that they will spin-off their Power & RF Division. This division is now called Wolfspeed. Wolfspeed is leading the innovation and commercialization of next-generation power and wireless systems based on silicon carbide and gallium nitride.

The CMPA601C025F from Cree is a GaN HEMT MMIC amplifier that operates from 6 GHz to 12 GHz. It has a small signal gain of up to 37 dB, can provide 35 W of saturated power and requires a 28 V supply. The amplifier is housed in thermally-enhanced, 10 lead ceramic package and is matched to 50 ohms.

Manufacturer Wolfspeed

Description High Efficiency GaN HEMT MMIC from 6 GHz to 12 GHz

Type GaN Amplifier, Power Amplifier

Configuration Module

Application General Purpose, Commercial, Military, Test & Measurement, Jamming Systems

Bits -5 to -2.1 dB

Frequency  6 to 12 GHz

Gain 33 dB

Saturated Power  35 W

Output Power  46.2 dBm

Output Power 41.68 W

PAE 27% to 31%

Supply Voltage 28 V

Impedance 50 Ohms

Output Return Loss  -5 to -2.4 dB

Package Type Surface Mount, Ceramic

Dimensions 0.172 x 0.239 x 0.004 inches

HMC8500

The HMC8500 from Analog Devices is a GaN power amplifier that operates from 0.01 GHz to 2.8 GHz. It delivers an output power of more than 10 W, a gain of 16 dB with a 55% power added efficiency (PAE). The device requires a power supply of 28 V and consumes up to 100 mA of current. It is available in a 32-lead, LFCSP package that measures 5 x 5 mm and is ideal for pulsed or continuous wave (CW) applications, such as wireless infrastructure, radars, public mobile radios, and general-purpose amplification. The amplifier is externally tuned using low cost, surface-mount components.
