AD9739BBCZ 14-Bit, 2.5 GSPS, RF Digital-to-Analog Converter

AD9739BBCZ 14-Bit, 2.5 GSPS, RF Digital-to-Analog Converter

• AD9739BBCZ


• Direct RF synthesis at 2.5 GSPS update rate

• DC to 1.25 GHz in baseband mode

• 1.25 GHz to 3.0 GHz in mix mode

• Industry leading single/multicarrier IF or RF synthesis

• fOUT = 350 MHz, ACLR =80 dBc

• fOUT = 950 MHz, ACLR = 78 dBc

• fOUT = 2100 MHz, ACLR = 69 dBc

• Dual-port LVDS data interface


• Up to 1.25 GSPS operation

• Source synchronous DDR clocking

• Pin-compatible with the AD9739A

• Multichip synchronization capability

• Programmable output current: 8.7 mA to 31.7 mA

• Low power: 1.16 W at 2.5 GSPS

AD9739BBCZ

The AD9739 is a 14-bit, 2.5 GSPS high performance RF digital-to-analog converter (DAC) capable of synthesizing wideband signals from dc up to 3.0 GHz. Its DAC core features a quad-switch architecture that provides exceptionally low distortion performance with an industry-leading direct RF synthesis capability. This feature enables multicarrier generation up to the Nyquist frequency in baseband mode as well as second and third Nyquist zones in mix mode. The output current can be programmed over the 8.66 mA to 31.66 mA range.

The inclusion of on-chip controllers simplifies system integration. A dual-port, source synchronous, LVDS interface simplifies the digital interface with existing FGPA/ASIC technology. On-chip controllers are used to manage external and internal clock domain variations over temperature to ensure reliable data transfer from the host to the DAC core. Multichip synchronization is possible with an on-chip synchronization controller. A serial peripheral interface (SPI) is used for device configuration as well as readback of status registers.

The AD9739 is manufactured on a 0.18 μm CMOS process and operates from 1.8 V and 3.3 V supplies. It is supplied in a 160-ball chip scale ball grid array for reduced package parasitics.

Product Highlights

1. Ability to synthesize high quality wideband signals with bandwidths of up to 1.25 GHz in the first or second Nyquist zone.

2. A proprietary quad-switch DAC architecture provides exceptional ac linearity performance while enabling mix mode operation.

3. A dual-port, double data rate, LVDS interface supports the maximum conversion rate of 2500 MSPS.

4. On-chip controllers manage external and internal clock domain skews.

5. A multichip synchronization capability.

6. Programmable differential current output with an 8.66 mA to 31.66 mA range.

AD9739BBCZ Applications

• Broadband communications systems

  Instrumentation, automatic test equipment

• Radar, avionics

•

AD574ASD/883  Complete 12-Bit A/D Converter

The AD574A is a complete 12-bit successive-approximation analog-to-digital converter with 3-state output buffer circuitry for direct interface to an 8- or 16-bit microprocessor bus. A high precision voltage reference and clock are included on-chip, and the circuit guarantees full-rated performance without external circuitry or clock signals.

AD574ASD/883 Overview

The AD574A design is implemented using Analog Devices' Bipolar/I2L process, and integrates all analog and digital functions on one chip. Offset, linearity and scaling errors are minimized by active laser-trimming of thin-film resistors at the wafer stage. The voltage reference uses an implanted buried Zener for low noise and low drift. On the digital side, I2L logic is used for the successive-approximation register, control circuitry and 3-state output buffers.

The AD574A is available in six different grades. The AD574AJ, K, and L grades are specified for operation over the 0°C to +70°C temperature range. The AD574AS, T, and U are specified for the -55°C to +125°C range. All grades are available in a 28-pin hermetically-sealed ceramic DIP. Also, the J, K, and L grades are available in a 28-pin plastic DIP and PLCC, and the J and K grades are available in ceramic LCC.

The S, T, and U grades in ceramic DIP or LCC are available with optional processing to MIL-STD-883C Class B; the T and U grades are available as JAN QPL. The Analog Devices' Military Products Databook should be consulted for details on /883B testing of the AD574A.

• Complete 12-Bit A/D Converter with Reference and Clock

• 8- and 16-Bit Microprocessor Bus Interface

• Guaranteed Linearity Over Temperature
  0°C to +70°C – AD574AJ, K, L
  –55°C to +125°C – AD574AS, T, U

• No Missing Codes Over Temperature

• 35 μs Maximum Conversion Time

• Buried Zener Reference for Long-Term Stability and Low Gain T.C. 10 ppm/°C max AD574AL 12.5 ppm/°C max AD574AU

ADC12D1620QML-SP  12-Bit, Dual 1.6-GSPS or Single 3.2-GSPS, RF-Sampling Analog-to-Digital Converter (ADC) - Aerospace
