Voltage 24v Brushless dc Motor
- Hong Kong
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | TT Motor | |
| Model Number | GMP24-TEC2419 | Usage | Car, Home Appliance, Other, Car, Home Appliance, optical equipment | |
| Certification | ROHS, Other, ROHS, QS9000,TS16949,ISO14000 | Type | Other, Brushless gear motor | |
| Torque | Max 30Kg.cm | Construction | Permanent Magnet | |
| Commutation | Brushless | Protect Feature | Totally Enclosed | |
| Speed(RPM) | Min 5 rpm | Continuous Current(A) | 110-160 mA | |
| Output Power | 1-5 W | Voltage(V) | 7-28 V | |
| Efficiency | Other, 75% |
Product Description
Model No: GMP24-TEC2419
voltage 24v brushless dc motor
1.small size dc gear moto rwith low speed and big torque
2.24mm gear motor provide 0.5Nm torque max and more reliable
3.suitable to small diameter, low noise and big torque application
uction ratio: 4,19,27,51,71,100,139,189,264,369,516,720,3730
5.motor default direction:CCW
ing temperature:-40~+60°c
7.PWM speed control and FG signal feedback.
8.Offer overload current protection
9.High quality, reasonable price and excellent after-sales service
1. Bank System: ATM Machine, Money Detector, Financial Apparatus
2. Vending Machine: Beverage Vending Machine, Coffee Vending Machine, Slot machine, advertising machine
3. Sanitary Applications: Towel dispenser, soap dispenser, air freshener dispenser, hand dryer ,hair dryer
4. Medical Equipments: Automative Blood Press Monitor, Dosing Equipment, Portable Air Pump, Diaphragm Pump
5.Home Appliance: Kitchen Appliance, TV Lift, Auto Cleaner, Auto Toilet Lid, Micro Vacuum Cleaner, Electric Curtain, Electric Fan
6.Robot and Robot Arm, Electrical Scooter
7.Office Products: Printer, Paper Shredder, Label Machine, Intelligent Electronic Device
Other applications such as bake machine, package machine, warm-light, horse feeders, electric valve, machinery equipment.....
