Metal Packing

FOB Price

USD $1,079.5 - $1,599.9 / Cubic Meter

1 Cubic Meter(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangxi, China		Brand Name	ZY
Model Number	500BX

1.acid&alkali function,long service life
2.Uniform contacting surface area
3.large void space, thin wall,small resistance

Main Specification of Metal Structured Packings (Stainless steel 304)
Name	Type	Surface Area m²/m³	Void Fraction %	Height mm	Bulk Density kg/m³	Max Factor m/s(kg/m³)^0.5	Theoretical Plate M^-1	Pressure Drop (p)
Perforated & Corrugated Plate	125	125	98	25.4	85~100	3	1~2	150
	250	250	97	12.5	170~200	2.6	2~3	200
	350	350	94	9	240~280	2	2.0~2.5	300
	500	500	92	6.3	360~400	1.8	4~5	180

Pricked & Corrugated Plate	250Y	250	97	12.5	85~100	2.6	5~7	900
	500Y	500	93	6.3	170~200	2.1	3~4	200
	700Y	700	85	4.5	240~280	1.6	2.5~3	300

Corrugated Plate Gauze	SW-1	650	91.6	4.5	140	1.4~2.2	6~8	260~460
Corrugated Plate Gauze	SW-2	450	95.5	6.5	360	1.6~1.8	4~5	220~240

Corrugated Wire Gauze	250(AX)	250	97	12.5	70	2.5~3.5	2.5~3	25~120
	500(BX)	500	95	6.3	140	2.0~2.4	4~5	200
	700(CY)	700	87	4.5	180	1.5~2.0

Sample photo:

Exported package photo:

Our advantage:

1. We will supply with the best price in 24 hours.

2. We will supply with all information to u ,about package, weight,

3. Except the size we have now , We also can produce special size as u need

4. We can communicate with u by Fluently and professional Enlish .

5. If u are urgent, U can add my Skype: zhouzhoufen , or Call me at any time: 8613979955589

6. For all products u buy, Our product's warranty is for 2 years. For product problem, u can contact with us any time.
