500X Metal Corrugated Gauze Packing
USD $1,079.5 - $1,599.9
/ Cubic Meter
1 Cubic Meter(Min.Order)
- 100 Cubic Meter / Cubic Meters per Month
- Shenzhen Shanghai and any port in China
- T/T Credit Card
You May Like
-
250Y Metal Structure packing
-
Metal Peforated Corrugated Packing(304.316)
-
316 Stainless Steel Metal Corrugated Packing
-
Ceramic structured packing
-
Ceramic acid resistance plate,micro porous ceramic filter media,ceramic plate
-
Acid resistant ceramic,Ceramic structured packing,ceramic corrugated stuctrued packing,tower internals
Product Details
| Place of Origin | Jiangxi, China | Brand Name | ZY | |
| Model Number | 500BX |
Product Description
Specifications
1.acid&alkali function,long service life2.Uniform contacting surface area
3.large void space, thin wall,small resistance
| Main Specification of Metal Structured Packings (Stainless steel 304) | ||||||||
| Name | Type | Surface Area m2/m3 | Void Fraction % | Height mm | Bulk Density kg/m3 | Max Factor m/s(kg/m3)0.5 | Theoretical Plate M-1 | Pressure Drop (p) |
| Perforated & Corrugated Plate | 125 | 125 | 98 | 25.4 | 85~100 | 3 | 1~2 | 150 |
| 250 | 250 | 97 | 12.5 | 170~200 | 2.6 | 2~3 | 200 | |
| 350 | 350 | 94 | 9 | 240~280 | 2 | 2.0~2.5 | 300 | |
| 500 | 500 | 92 | 6.3 | 360~400 | 1.8 | 4~5 | 180 | |
| Pricked & Corrugated Plate | 250Y | 250 | 97 | 12.5 | 85~100 | 2.6 | 5~7 | 900 |
| 500Y | 500 | 93 | 6.3 | 170~200 | 2.1 | 3~4 | 200 | |
| 700Y | 700 | 85 | 4.5 | 240~280 | 1.6 | 2.5~3 | 300 | |
| Corrugated Plate Gauze | SW-1 | 650 | 91.6 | 4.5 | 140 | 1.4~2.2 | 6~8 | 260~460 |
| SW-2 | 450 | 95.5 | 6.5 | 360 | 1.6~1.8 | 4~5 | 220~240 | |
| Corrugated Wire Gauze | 250(AX) | 250 | 97 | 12.5 | 70 | 2.5~3.5 | 2.5~3 | 25~120 |
| 500(BX) | 500 | 95 | 6.3 | 140 | 2.0~2.4 | 4~5 | 200 | |
| 700(CY) | 700 | 87 | 4.5 | 180 | 1.5~2.0 | |||
Metal Corrugated Gauze packing informations:
protruded corrugated sheet packing forming by the following way that first press forming small intensity 0.4-0.5 hole, then stamp sheet with multi-thorn orifice plate form into corrugated combination regular packing, Because the special orifice structure of surface to enhance the packing wet ability ,and keep the character of the packings.
Available Materia of metal tower packing : Stainless steel, copper, aluminum and so on.
We can produce according to your tower size .
Welcome to inquiry our products
