Indoor Fiber Cable

FOB Price

US$ 0.1 - 1 / Kilometer

1 Kilometer(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	NECERO
Model Number	Distribution Cable

Indoor cable 02~12 fiber, 900um Tight buffer fiber, Aramid yarn, PVC/LSZH Jacket.

Product image

Standards

Comply with Standard YD/T 1258.4-2005, ICEA-596, GR-409, IEC794, etc; and meet the requirements of UL approval for OFNR.

Cable Code

Mechanical Characteristics

Optical Characteristics

50/125μm	62.5/125μm	G.652	G.655
Attenuation(+20°C)	@850nm	≤3.5dB/km	≤3.5dB/km
	@1300nm	≤1.5dB/km	≤1.5dB/km
	@1310nm			≤0.45dB/km	≤0.50dB/km
	@1550nm			≤0.30dB/km	≤0.50dB/km
Bandwidth (Class A)	@850nm	≥500MHz·km	≥200MHz·km
Bandwidth (Class A)	@1300nm	≥1000MHz·km	≥600MHz·km
Numerical Aperture		0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc				≤1260nm	≤1480nm
Attenuation at temperature cycling Δα(-20°C~+85°C)	@1300nm	≤0.50dB/km	≤0.50dB/km
Attenuation at temperature cycling Δα(-20°C~+85°C)	@1550nm			≤0.20dB/km	≤0.20dB/km

Environmental Characteristics
