Home > Products > Indoor Fiber Optic Cable > Fiber Optic Pigtail Cable
Fiber Optic Pigtail Cable
- shenzhen yantian
- T/T D/P D/A
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | NECERO | |
| Model Number | GJFJV | Type | Coaxial | |
Product Description
Our customers
Description
NECERO indoor fiber optical cable is made by evenly applying strands of Aramid yarns as the strength member over tight buffer fibers and then is completed with a flame-retardant sheath.
Characteristics
Good uniformity of the outer diameter of tight buffer fiber and excellent strippabilityGood performance of flame-retardantLow induced attenuation within the operating temperature range Excellent geometrical dimension of the fiber
Application Data communicationMaking connectorInstallation: riser, plenum, etc.Places where waterproof is not strictly required Making jumper, pigtail and building distribution
Description
1fiber, Φ900μm or Φ600μm Tight buffer fiber, Aramid yarn, LSZH Jacket.
Standards
Comply with Standard YD/T 1258.2-2003, ICEA-596, GR-409, IEC794, etc; and meet the requirements of UL approval for OFNR and OFNP.
Cable Code
| SXC-II | SXC-I | |
Cable Diameter | 2.8±0.2mm | 2.0±0.2mm | 1.6±0.2mm |
Cable Weight | 6.9kg/km | 5.9kg/km | 4.0kg/km |
TBF Diameter | 900±50μm | 900±50μm | 600±50μm |
Mechanical Characteristics
Tensile Strength | Long term | 80N | 60N | ||
Short term | 150N | 120N | |||
Crush Resistance | Long term | 100N/100mm | |||
Short term | 500N/100mm | ||||
Bending Radius | Dynamic | 20×D (Cable Diameter) | |||
Static | 10×D (Cable Diameter) | ||||
Environmental Characteristics
| -20°C~+60°C |
Storage Temperature | -20°C~+60°C |
Installation Temperature | -5°C~+50°C |
Operating Temperature | -20°C~+60°C |
